575-303 | SERIES 575 ̶ ABSOLUTE Digimatic Linear Gage | MITUTOYO
THB 0.00
พร้อมส่ง
SKU
573-303
• ABSOLUTE electrostatic capacitance type encoder makes it possible to maintain the reference point even when the power is switched off.
• Excellent protection against dust and splashing water (IP66) on the factory floor.
Specifications
| Order No. | 575-303 | |
| Measuring range | 12.7 mm | |
| Resolution | 10 μm | |
| Measuring accuracy (20 ℃) | 15 μm | |
| Measuring force | Contact point downwards | 2.0 N or less |
| Contact point horizontal | 1.8 N or less | |
| Contact point upwards | 1.6 N or less | |
| Position detection method | ABSOLUTE electrostatic capacitance type linear encoder | |
| Response speed | Unlimited (not applicable to scanning measurement) | |
| Output | Digimatic output | |
| Mass | Approx. 190 g | |
| Protection Level | Equivalent to IP66 (only gage head) | |
| Contact point | ø3 mm carbide-tipped (fixing screw: M2.5 (P=0.45) ×5), standard contact point: 901312 | |
| Stem | ø8 mm | |
| Bearing | Plain type | |
| Output cable length | 2 m (directly extended from the main unit) | |
| Operating temperature (humidity) | 0 to 40 °C (RH 20 to 80%, non-condensing) | |
| Storage temperature (humidity) | –10 to 60 °C (RH 20 to 80%, non-condensing) | |
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Order No. | 575-303 (LGS-1012P) |
| Measuring Range | 12.7 mm |
| Resolution | 10 μm |
| Measuring accuracy (20 ℃) | 15 μm |
| Measuring force | Contact point downwards : 2.0 N or less Contact point horizontal : 1.8 N or less Contact point upwards : 1.6 N or less |
| Position detection method | ABSOLUTE electrostatic capacitance type linear encoder |
| Response speed | Unlimited (not applicable to scanning measurement) |
| Output | Digimatic output |
| Protection Level | Equivalent to IP66 (only gage head) |
| Contact point | ø3 mm carbide-tipped (fixing screw: M2.5 (P=0.45) ×5), standard contact point: 901312 |
| Stem | ø8 mm |
| Bearing | Plain type |
| Output cable length | 2 m (directly extended from the main unit) |
| Operating temperature (humidity) | 0 to 40 °C (RH 20 to 80%, non-condensing) |
| Storage temperature (humidity) | –10 to 60 °C (RH 20 to 80%, non-condensing) |
