EPBT2 | CARBIDE BALL END MILL | MOLDINO
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 2,340.09
พร้อมส่ง
SKU
HIT-EPBT2
For high-hardness materials (Ideal for materials with hardnesses of 40HRC or higher)
| แบรนด์สินค้า | MOLDINO |
|---|---|
| โมเดล | EPBT |
|
商品コード |
在庫Stock |
寸 法 Size(mm) |
形状 Shape |
|||||||
| ボール半径 Ball radius |
外径 Tool dai |
刃長 |
首下長 Under neck length |
シャンク径 |
||||||
| RE | DC | APMX | LB2 | LB3 | ℓ4 | LF |
DCONMS |
|||
| EPBT2010 | ● | 0.5 | 1 | 1.5 | 2.5 | 11 | 8.5 | 50 | 4 | A |
| EPBT2015 | ● | 0.75 | 1.5 | 2.5 | 3.5 | 10.6 | 7.1 | 50 | 4 | A |
| EPBT2020 | ● | 1 | 2 | 3 | 4 | 15.3 | 11.3 | 50 | 6 | A |
| EPBT2025 | ● | 1.25 | 2.5 | 4 | 5 | 14.9 | 9.9 | 50 | 6 | A |
| EPBT2030 | ● | 1.5 | 3 | 4.5 | 5.5 | 14 | 8.5 | 70 | 6 | A |
| EPBT2040-4 | ● | 2 | 4 | 6 | - | - | - | 70 | 4 | B |
| EPBT2040 | ● | 2 | 4 | 6 | 7 | 12.7 | 5.7 | 70 | 6 | A |
| EPBT2050 | ● | 2.5 | 5 | 7.5 | 8.5 | 11.3 | 2.8 | 80 | 6 | A |
| EPBT2060 | ● | 3 | 6 | 9 | - | - | - | 90 | 6 | B |
| EPBT2080 | ● | 4 | 8 | 12 | - | - | - | 100 | 8 | B |
| EPBT2100 | ● | 5 | 10 | 15 | - | - | - | 100 | 10 | B |
| EPBT2120 | ● | 6 | 12 | 18 | - | - | - | 110 | 12 | B |
| EPBT2160 | ● | 8 | 16 | 24 | - | - | - | 140 | 16 | B |
| EPBT2200 | ● | 10 | 20 | 30 | - | - | - | 160 | 20 | B |
