EPDBEH2-F-TH3 | CARBIDE BALL END MILL | MOLDINO เครื่องมืออุตสาหกรรม เครื่องมือช่าง เครื่องมือวัดละเอียด

ข้อมูลเพิ่มเติม
แบรนด์สินค้า	MOLDINO
โมเดล	EPDBEH-F-TH3

Dimension

商品コード Item Code	在庫 Stock	寸　法 Size(mm)							タイプ Type	干渉角度 Interference angle (º)	勾配角に対する実有効首下長 Effective under neck length with respect to draft angle
		ボール半径 Ball radius	外径 Tool dai	首下長 Under neck length	刃長 Flute length	首径 Neck dai	全長 Overall length	シャンク径 Shank dai		干渉角度 Interference angle (º)
		RE	DC	LU	APMX	DN	LF	DCONMS		θκ	0.5º	1º	1.5º	2º	3º
EPDBEH2001F-0.08-TH3	⬤	0.05	0.1	0.08	0.08	-	35	4	B	20.93	-	-	-	-	-
EPDBEH2001F-0.2-TH3	⬤			0.2	0.08	0.08	35	4	A	14.64	0.24	0.25	0.25	0.26	0.28
EPDBEH2001F-0.3-TH3	⬤			0.3	0.08	0.08	35	4	A	14.46	0.34	0.35	0.36	0.38	0.40
EPDBEH2001F-0.5-TH3	⬤			0.5	0.08	0.08	35	4	A	14.10	0.55	0.57	0.59	0.61	0.65
EPDBEH20015F-0.12-TH3	⬤	0.075	0.15	0.12	0.12	-	35	4	B	15.25	-	-	-	-	-
EPDBEH20015F-0.3-TH3	⬤			0.3	0.12	0.13	35	4	A	14.50	0.34	0.35	0.36	0.37	0.40
EPDBEH20015F-0.5-TH3	⬤			0.5	0.12	0.13	35	4	A	14.14	0.55	0.56	0.58	0.60	0.65
EPDBEH20015F-0.75-TH3	⬤			0.75	0.12	0.13	35	4	A	13.71	0.81	0.83	0.86	0.89	0.96
EPDBEH2002F-0.15-TH3	⬤	0.1	0.2	0.15	0.15	-	35	4	B	20.23	-	-	-	-	-
EPDBEH2002F-0.3-TH3	⬤			0.3	0.15	0.18	35	4	A	14.54	0.34	0.35	0.36	0.37	0.39
EPDBEH2002F-0.5-TH3	⬤			0.5	0.15	0.18	35	4	A	14.17	0.55	0.56	0.58	0.60	0.64
EPDBEH2002F-0.75-TH3	⬤			0.75	0.15	0.18	35	4	A	13.73	0.81	0.83	0.86	0.89	0.95
EPDBEH2002F-1-TH3	⬤			1	0.15	0.18	38	4	A	13.32	1.06	1.10	1.13	1.17	1.26
EPDBEH2003F-0.25-TH3	⬤	0.15	0.3	0.25	0.25	-	35	4	B	14.21	-	-	-	-	-
EPDBEH2003F-0.5-TH3	⬤			0.5	0.25	0.27	35	4	A	14.21	0.56	0.58	0.60	0.61	0.65
EPDBEH2003F-0.75-TH3	⬤			0.75	0.25	0.27	35	4	A	13.76	0.82	0.85	0.87	0.90	0.96
EPDBEH2003F-1-TH3	⬤			1	0.25	0.27	35	4	A	13.33	1.08	1.11	1.15	1.19	1.27
EPDBEH2003F-1.5-TH3	⬤			1.5	0.25	0.27	38	4	A	12.56	1.60	1.65	1.70	1.76	1.89
EPDBEH2004F-0.3-TH3	⬤	0.2	0.4	0.3	0.3	-	35	4	B	14.53	-	-	-	-	-
EPDBEH2004F-0.5-TH3	⬤			0.5	0.3	0.37	35	4	A	14.28	0.56	0.58	0.59	0.60	0.64
EPDBEH2004F-0.75-TH3	⬤			0.75	0.3	0.37	35	4	A	13.81	0.82	0.84	0.87	0.89	0.95
EPDBEH2004F-1-TH3	⬤			1	0.3	0.37	35	4	A	13.37	1.08	1.11	1.14	1.18	1.26
EPDBEH2004F-1.5-TH3	⬤			1.5	0.3	0.37	38	4	A	12.56	1.60	1.65	1.70	1.76	1.89
EPDBEH2004F-2-TH3	⬤			2	0.3	0.37	38	4	A	11.68	2.11	2.18	2.25	2.33	2.50
EPDBEH2004F-2.5-TH3	⬤			2.5	0.3	0.37	38	4	A	11.23	2.63	2.72	2.81	2.90	3.13
EPDBEH2004F-3-TH3	⬤			3	0.3	0.37	38	4	A	10.65	3.15	3.25	3.36	3.48	3.75
EPDBEH2004F-4-TH3	⬤			4	0.3	0.37	38	4	A	9.67	4.18	4.32	4.47	4.63	4.99
EPDBEH2005F-0.75-TH3	⬤	0.25	0.5	0.75	0.35	0.47	35	4	A	13.88	0.82	0.84	0.86	0.88	0.94
EPDBEH2005F-1-TH3	⬤			1.0	0.35	0.47	35	4	A	13.42	1.08	1.11	1.14	1.17	1.25
EPDBEH2005F-1.5-TH3	⬤			1.5	0.35	0.47	38	4	A	12.59	1.59	1.64	1.69	1.75	1.87
EPDBEH2005F-2-TH3	⬤			2.0	0.35	0.47	38	4	A	11.86	2.11	2.18	2.25	2.32	2.49
EPDBEH2005F-2.5-TH3	⬤			2.5	0.35	0.47	38	4	A	11.21	2.63	2.71	2.8	2.9	3.11
EPDBEH2005F-3-TH3	⬤			3.0	0.35	0.47	38	4	A	10.62	3.15	3.25	3.36	3.47	3.73
EPDBEH2005F-4-TH3	⬤			4.0	0.35	0.47	38	4	A	9.61	4.18	4.32	4.46	4.62	4.98
EPDBEH2005F-5-TH3	⬤			5.0	0.35	0.47	42	4	A	8.78	5.21	5.39	5.57	5.77	6.22
EPDBEH2006F-0.4-TH3	⬤	0.3	0.6	0.4	0.4	-	35	4	B	14.16	-	-	-	-	-
EPDBEH2006F-0.75-TH3	⬤			0.75	0.4	0.57	35	4	A	13.94	0.82	0.84	0.86	0.88	0.93
EPDBEH2006F-1-TH3	⬤			1.0	0.4	0.57	35	4	A	13.47	1.08	1.1	1.13	1.17	1.24
EPDBEH2006F-1.5-TH3	⬤			1.5	0.4	0.57	35	4	A	12.61	1.59	1.64	1.69	1.74	1.86
EPDBEH2006F-2-TH3	⬤			2.0	0.4	0.57	38	4	A	11.86	2.11	2.17	2.24	2.31	2.48
EPDBEH2006F-2.5-TH3	⬤			2.5	0.4	0.57	38	4	A	11.19	2.63	2.71	2.8	2.89	3.1
EPDBEH2006F-3-TH3	⬤			3.0	0.4	0.57	38	4	A	10.59	3.14	3.24	3.35	3.46	3.72
EPDBEH2006F-3.5-TH3	⬤			3.5	0.4	0.57	38	4	A	10.05	3.66	3.78	3.9	4.04	4.34
EPDBEH2006F-4-TH3	⬤			4.0	0.4	0.57	38	4	A	9.56	4.18	4.31	4.46	4.61	4.97
EPDBEH2006F-5-TH3	⬤			5.0	0.4	0.57	42	4	A	8.71	5.21	5.38	5.57	5.76	6.21
EPDBEH2006F-6-TH3	⬤			6.0	0.4	0.57	42	4	A	8.0	6.24	6.45	6.67	6.91	7.45
EPDBEH2007F-0.45-TH3	⬤	0.35	0.7	0.45	0.45	-	35	4	B	14.13	-	-	-	-	-
EPDBEH2007F-2-TH3	⬤			2.0	0.45	0.67	38	4	A	11.85	2.11	2.17	2.24	2.31	2.47
EPDBEH2007F-4-TH3	⬤			4.0	0.45	0.67	38	4	A	9.5	4.18	4.31	4.45	4.61	4.95
EPDBEH2008F-0.5-TH3	⬤	0.4	0.8	0.5	0.5	nan	35	4	B	14.2	-	-	-	-	-
EPDBEH2008F-1-TH3	⬤			1.0	0.5	0.77	35	4	A	13.58	1.07	1.1	1.12	1.15	1.21
EPDBEH2008F-1.5-TH3	⬤			1.5	0.5	0.77	35	4	A	12.66	1.59	1.63	1.68	1.73	1.83
EPDBEH2008F-2-TH3	⬤			2.0	0.5	0.77	38	4	A	11.85	2.11	2.17	2.23	2.3	2.46
EPDBEH2008F-2.5-TH3	⬤			2.5	0.5	0.77	38	4	A	11.14	2.62	2.7	2.79	2.88	3.08
EPDBEH2008F-3-TH3	⬤			3.0	0.5	0.77	38	4	A	10.51	3.14	3.24	3.34	3.45	3.7
EPDBEH2008F-4-TH3	⬤			4.0	0.5	0.77	38	4	A	9.44	4.17	4.31	4.45	4.6	4.94
EPDBEH2008F-5-TH3	⬤			5.0	0.5	0.77	42	4	A	8.57	5.21	5.38	5.56	5.75	6.19
EPDBEH2008F-6-TH3	⬤			6.0	0.5	0.77	42	4	A	7.84	6.24	6.45	6.66	6.9	7.43
EPDBEH2008F-8-TH3	⬤			8.0	0.5	0.77	42	4	A	6.7	8.31	8.58	8.88	9.2	9.92
EPDBEH2009F-0.6-TH3	⬤	0.45	0.9	0.6	0.6	-	35	4	B	13.84	-	-	-	-	-
EPDBEH2009F-2-TH3	⬤		0.9	2.0	0.6	0.87	35	4	A	11.85	2.11	2.16	2.23	2.29	2.44
EPDBEH2009F-4-TH3	⬤		0.9	4.0	0.6	0.87	38	4	A	9.38	4.17	4.3	4.44	4.59	4.93
EPDBEH2009F-6-TH3	⬤		0.9	6.0	0.6	0.87	42	4	A	7.75	6.24	6.44	6.66	6.89	7.42
EPDBEH2010F-0.8-TH3	⬤	0.5	1.0	0.8	0.8	-	35	4	B	13.47	-	-	-	-	-
EPDBEH2010F-1.5-TH3	⬤			1.5	0.8	0.96	35	4	A	12.67	1.61	1.64	1.69	1.73	1.83
EPDBEH2010F-2-TH3	⬤			2.0	0.8	0.96	35	4	A	11.82	2.12	2.18	2.24	2.31	2.46
EPDBEH2010F-2.5-TH3	⬤			2.5	0.8	0.96	38	4	A	11.07	2.64	2.71	2.8	2.88	3.08
EPDBEH2010F-3-TH3	⬤			3.0	0.8	0.96	38	4	A	10.41	3.16	3.25	3.35	3.46	3.7
EPDBEH2010F-4-TH3	⬤			4.0	0.8	0.96	38	4	A	9.29	4.19	4.32	4.46	4.61	4.94
EPDBEH2010F-5-TH3	⬤			5.0	0.8	0.96	38	4	A	8.39	5.22	5.39	5.57	5.76	6.19
EPDBEH2010F-6-TH3	⬤			6.0	0.8	0.96	42	4	A	7.65	6.26	6.46	6.67	6.91	7.43
EPDBEH2010F-7-TH3	⬤			7.0	0.8	0.96	42	4	A	7.03	7.29	7.53	7.78	8.06	8.67
EPDBEH2010F-8-TH3	⬤			8.0	0.8	0.96	42	4	A	6.5	8.32	8.6	8.89	9.21	9.91
EPDBEH2010F-10-TH3	⬤			10.0	0.8	0.96	45	4	A	5.65	10.39	10.74	11.11	11.51	12.4
EPDBEH2010F-12-TH3	⬤			12.0	0.8	0.96	45	4	A	5.0	12.46	12.88	13.32	13.81	14.89
EPDBEH2015F-2-TH3	⬤	0.75	1.5	2.0	1.35	1.45	35	4	A	11.76	2.13	2.18	2.23	2.29	2.42
EPDBEH2015F-2.5-TH3	⬤			2.5	1.35	1.45	35	4	A	10.88	2.65	2.72	2.79	2.87	3.04
EPDBEH2015F-3-TH3	⬤			3.0	1.35	1.45	35	4	A	10.12	3.17	3.25	3.34	3.44	3.66
EPDBEH2015F-4-TH3	⬤			4.0	1.35	1.45	38	4	A	8.88	4.2	4.32	4.45	4.59	4.91
EPDBEH2015F-5-TH3	⬤			5.0	1.35	1.45	38	4	A	7.9	5.23	5.39	5.56	5.74	6.15
EPDBEH2015F-6-TH3	⬤			6.0	1.35	1.45	38	4	A	7.12	6.27	6.46	6.67	6.89	7.39
EPDBEH2015F-8-TH3	⬤			8.0	1.35	1.45	42	4	A	5.95	8.34	8.6	8.88	9.19	9.88
EPDBEH2015F-10-TH3	⬤			10.0	1.35	1.45	42	4	A	5.1	10.4	10.74	11.1	11.49	12.36
EPDBEH2015F-12-TH3	⬤			12.0	1.35	1.45	45	4	A	4.47	12.47	12.88	13.32	13.79	14.85
EPDBEH2020F-2.5-TH3	⬤	1.0	2.0	2.5	1.7	1.94	35	4	A	10.6	2.66	2.72	2.78	2.85	3.01
EPDBEH2020F-3-TH3	⬤			3.0	1.7	1.94	35	4	A	9.72	3.18	3.25	3.34	3.43	3.63
EPDBEH2020F-4-TH3	⬤			4.0	1.7	1.94	35	4	A	8.32	4.21	4.32	4.45	4.58	4.87
EPDBEH2020F-5-TH3	⬤			5.0	1.7	1.94	38	4	A	7.27	5.25	5.39	5.55	5.73	6.11
EPDBEH2020F-6-TH3	⬤			6.0	1.7	1.94	38	4	A	6.46	6.28	6.46	6.66	6.88	7.36
EPDBEH2020F-8-TH3	⬤			8.0	1.7	1.94	42	4	A	5.27	8.35	8.6	8.88	9.18	9.84
EPDBEH2020F-10-TH3	⬤			10.0	1.7	1.94	42	4	A	4.46	10.41	10.74	11.1	11.48	12.33
EPDBEH2020F-12-TH3	⬤			12.0	1.7	1.94	45	4	A	3.86	12.48	12.88	13.31	13.77	14.82
EPDBEH2020F-13-TH3	⬤			13.0	1.7	1.94	45	4	A	3.62	13.51	13.95	14.42	14.92	16.06
EPDBEH2020F-14-TH3	⬤			14.0	1.7	1.94	45	4	A	3.4	14.55	15.02	15.53	16.07	17.3
EPDBEH2020F-16-TH3	⬤			16.0	1.7	1.94	50	4	A	3.04	16.62	17.16	17.75	18.37	19.79
EPDBEH2020F-20-TH3	⬤			20.0	1.7	1.94	55	4	A	2.51	20.75	21.44	22.18	22.97	干渉なし
EPDBEH2025F-6-TH3	⬤	1.25	2.5	6.0	2.0	2.4	38	4	A	5.54	6.35	6.53	6.72	6.92	7.39
EPDBEH2025F-10-TH3	⬤			10.0	2.0	2.4	42	4	A	3.66	10.48	10.81	11.15	11.52	12.36
EPDBEH2025F-15-TH3	⬤			15.0	2.0	2.4	45	4	A	2.57	15.65	16.15	16.69	17.27	干渉なし
