FRTS-Series | Food Texture Analyzer | IMADA
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 247,865.50
พร้อมส่ง
SKU
IMA-FRTS-Series
IMADA rheometer is desktop and portable, making it easier to handle on site and less expensive to install than larger test machines. Despite its small size, it is capable of acquiring 1000 data per second and has a high accuracy of ±0.2% F.S., making it possible to perform precise food texture test. The recommended measurement method for each food is pre-installed, and the measurement method can be arranged, so you can instantly start texture test immediately after purchase without any difficult settings. Software for graphing the measured values is included, and by programming the test conditions, various parameters such as adhesion and stickiness can be obtained, making texture analysis easy.
Feature
- Quantifies texture in force to evaluate the textural properties of food such as firmness, tackiness, cohesion, elasticity, etc.
- Reduces testing time by selecting food sample or a test standard, and preset conditions from the touch screen to confirm measuring condition
- Easy to perform food measurements complying with the corresponding part of ISO, JIS, and more
- Offers easy analysis of force-time/displacement by graphing and data management with the supplied software as well as direct data saving feature to USB drive
- Various shaped optional attachments available for handling a wide range of testing applications
Specifications
| Model | FRTS-5N | FRTS-50N | FRTS-100N | |
| Capacity | 5N | 50N | 100N | |
| Resolution | 5.000N | 50.00N | 100.0N | |
| Accuracy | Force | ±0.2%F.S±1digit | ||
| Displacement | 0.1mm±1digit | |||
| Unit | Force | N / Kgf / lbf (*) | ||
| Displacement | mm / inch (*) | |||
| Indication | Force | 4-digit | ||
| Displacement | 0.001mm (as the minimum resolution) | |||
| Sampling rate | 1000Hz | |||
| Sample maximum height | 70mm(*1) | |||
| Table travel distance | Max.100mm | |||
| Speed | 0.1 to 10.0mm/sec | |||
| Functions | 3 types of measuring method (Food/Standard(*2), Program, Manual), Add-a-favorites for measuring conditions (Max.6 conditions), Start-trigger function, Overload preventing function (*3) | |||
| Output | USB, USB flash drive | |||
| Accessory | Graphing software, Power cable, USB cable, USB flash drive, Attachment (4 kinds), FR-HN (screw for mounting lower tension attachments), FR-JS-50/100 (2 type shafts for mounting upper attachments), Fuse, Inspection certificate | |||
| Operating environment (*4) | Temperature: 0 to 40 degree Celsius Humidity: 20 to 80 %RH | |||
| Weight | Body: 7.7kg Control Panel: 0.8kg | |||
| Size | 185 x 300 x 400 mm (except its control panel) | |||
*The units are switchable. The units differs from Japanese domestic model.
*1 It is the maximum distance from its table surface to the part where an attachment is mounted.
*2 PC for measurement is required to comply with some standards.
*3 You cannot prevent overload in some cases. *4 Not able to use this product in a vibratile environment.
| แบรนด์สินค้า | IMADA |
|---|---|
| Order No. | FRTS-Series |
