HGOBLS2-PN | CARBIDE BALL END MILL | MOLDINO
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 3,701.13
พร้อมส่ง
SKU
HIT-HGOBLS2-PN
Provides good machined surface finish for rough machining with high cutting depth. Enables machining of a wide variety of subject materials.
| RE3〜RE6 | : | ±0.015 |
| RE8〜RE10 | : | ±0.02 |
| แบรนด์สินค้า | MOLDINO |
|---|---|
| โมเดล | HGOBLS-PN |
|
商品コード |
在庫Stock |
寸 法 Size(mm) |
刃数 |
形状 Shape |
|||||
| ボール半径 Ball radius |
外径 Tool dai |
刃長 |
首下長 Under neck length |
全長 Overall length |
シャンク径 Shank dia. |
||||
| RE | DC | APMX | LB2 | LF | DCONMS | ||||
| HGOBLS2060-45-PN | ● | 3 | 6 | 9 | 45 | 115 | 6 | 2 | A |
| HGOBLS2060-75-PN | ● | 3 | 6 | 9 | 75 | 150 | 6 | 2 | A |
| HGOBLS2080-55-PN | ● | 4 | 8 | 12 | 55 | 125 | 8 | 2 | A |
| HGOBLS2080-105-PN | ● | 4 | 8 | 12 | 105 | 180 | 8 | 2 | A |
| HGOBLS2100-PN | ● | 5 | 10 | 15 | 200 | 9 | 2 | B | |
| HGOBLS2120-PN | ● | 6 | 12 | 18 | 220 | 11 | 2 | B | |
| HGOBLS2160-PN | ● | 8 | 16 | 24 | 250 | 14 | 2 | B | |
| HGOBLS2200-PN | ● | 10 | 20 | 30 | 250 | 18 | 2 | B | |
