HTS | Carbide Taper End Mills | MOLDINO
ราคาต่ำสุด
THB 0.00
พร้อมส่ง
SKU
MOL-HTS
HTS
|
商品コード Item code |
在庫 Stock |
寸法 Size (mm) |
刃数 No. of flutes |
||||
|
外径 Tool dia. |
刃部テーパ半角 Taperangle on side |
刃長 Flute length |
全長 Overall length |
シャンク径 Shank dia. |
|||
| HTS2030-1 | ☐ | 3 | 30′ | 8 | 45 | 4 | 2 |
| HTS2030-2 | ☐ | 3 | 1° | 8 | 45 | 4 | 2 |
| HTS2030-3 | ☐ | 3 | 1°30′ | 8 | 45 | 4 | 2 |
| HTS2030-4 | ☐ | 3 | 2° | 8 | 45 | 4 | 2 |
| HTS2030-5 | ☐ | 3 | 2°30′ | 8 | 45 | 4 | 2 |
| HTS2030-6 | ☐ | 3 | 3° | 8 | 45 | 4 | 2 |
| HTS2040-1 | ☐ | 4 | 30′ | 12 | 45 | 4 | 2 |
| HTS2040-2 | ☐ | 4 | 1° | 12 | 45 | 4 | 2 |
| HTS2040-3 | ☐ | 4 | 1°30′ | 12 | 45 | 4 | 2 |
| HTS2040-4 | ☐ | 4 | 2° | 12 | 45 | 4 | 2 |
| HTS2040-5 | ☐ | 4 | 2°30′ | 12 | 45 | 4 | 2 |
| HTS2040-6 | ☐ | 4 | 3° | 12 | 45 | 4 | 2 |
| HTS2050-1 | ☐ | 5 | 30′ | 15 | 50 | 6 | 2 |
| HTS2050-2 | ☐ | 5 | 1° | 15 | 50 | 6 | 2 |
| HTS2050-3 | ☐ | 5 | 1°30′ | 15 | 50 | 6 | 2 |
| HTS2050-4 | ☐ | 5 | 2° | 15 | 50 | 6 | 2 |
| HTS2050-5 | ☐ | 5 | 2°30′ | 15 | 50 | 6 | 2 |
| HTS2050-6 | ☐ | 5 | 3° | 15 | 50 | 6 | 2 |
| HTS2060-1 | ☐ | 6 | 30′ | 18 | 60 | 6 | 2 |
| HTS2060-2 | ☐ | 6 | 1° | 18 | 60 | 6 | 2 |
| HTS2060-3 | ☐ | 6 | 1°30′ | 18 | 60 | 6 | 2 |
| HTS2060-4 | ☐ | 6 | 2° | 18 | 60 | 6 | 2 |
| HTS2060-5 | ☐ | 6 | 2°30′ | 18 | 60 | 6 | 2 |
| HTS2060-6 | ☐ | 6 | 3° | 18 | 60 | 6 | 2 |
| HTS2080-1 | ☐ | 8 | 30′ | 24 | 70 | 8 | 2 |
| HTS2080-2 | ☐ | 8 | 1° | 24 | 70 | 8 | 2 |
| HTS2080-3 | ☐ | 8 | 1°30′ | 24 | 70 | 8 | 2 |
| HTS2080-4 | ☐ | 8 | 2° | 24 | 70 | 8 | 2 |
| HTS2080-5 | ☐ | 8 | 2°30′ | 24 | 70 | 10 | 2 |
| HTS2080-6 | ☐ | 8 | 3° | 24 | 70 | 10 | 2 |
| HTS4100-1 | ☐ | 10 | 30′ | 30 | 75 | 10 | 4 |
| HTS4100-2 | ☐ | 10 | 1° | 30 | 75 | 10 | 4 |
| HTS4100-3 | ☐ | 10 | 1°30′ | 30 | 75 | 10 | 4 |
| HTS4100-4 | ☐ | 10 | 2° | 30 | 75 | 10 | 4 |
| HTS4100-5 | ☐ | 10 | 2°30′ | 30 | 75 | 12 | 4 |
| HTS4100-6 | ☐ | 10 | 3° | 30 | 75 | 12 | 4 |
| HTS4120-1 | ☐ | 12 | 30′ | 36 | 90 | 12 | 4 |
| HTS4120-2 | ☐ | 12 | 1° | 36 | 90 | 12 | 4 |
| HTS4120-3 | ☐ | 12 | 1°30′ | 36 | 90 | 12 | 4 |
| HTS4120-4 | ☐ | 12 | 2° | 36 | 90 | 12 | 4 |
| HTS4120-5 | ☐ | 12 | 2°30′ | 36 | 90 | 12 | 4 |
| HTS4120-6 | ☐ | 12 | 3° | 36 | 90 | 12 | 4 |
| แบรนด์สินค้า | MOLDINO |
|---|
レギュラー刃長 Regular
○ HTS、HTSL、HTSB、FE4の対応被削材
Applicable work material of HTS, HTSL, HTSB, FE4
|
炭素鋼 合金鋼 Carbon steel Alloy steel |
プリハードン鋼 Pre-hardened steel ≦ 45HRC |
高硬度 Hardened steel |
ステンレス鋼 Stainless steel |
チタン合金 耐熱合金 Titanium alloy Heat-resistant alloy |
銅合金 Copper alloy |
アルミ合金 Aluminum alloy |
||
|
＞45HRC ≦ 55HRC |
＞ 55HRC ≦ 65HRC |
＞ 65HRC | ||||||
| ○ | ○ | ○ | ○ | ◎ | ◎ | |||
□ 印：特定代理店在庫です。弊社営業へお問合せください。
□ ：Stocked by specified distributor. Contact with our sales department.
