Adjustable workstage (for LSM-30-A)
The mechanism allowing vertical and horizontal sliding helps to ensure easy outside diameter measurement of various workpieces. It is useful for quality control of precision shafts, rollers, and pin gages.
| Order No. | 02AGD490 |
| Measuring range | 0.3 to 30 mm |
| Horizontal stroke | 200 mm |
| Vertical stroke | 35 mm |
| Maximum loading mass | 2.0 kg |
| Mass | 4.9 kg |
| Standard Accessories | V-block (02AGD420) × 2 Stop (02AGD430) × 1 |
| Optional accessories | Center support (02AGD440) Adjustable V-block (up/down) (02AGD450) |
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Order No. | 02AGD490 |
