SERIES 102 | Outside Micrometers | MITUTOYO
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 1,797.60
พร้อมส่ง
SKU
1MIT-OM-102
• Standard analog micrometer. Thanks to a heat-insulated frame, it is resistant to heat and therefore delivers accurate measurement results.
• Cut-away frame (behind anvil) for measuring in hard-to-reach places. • Equipped with Ratchet Stop for constant measuring force.
• Measuring faces: Carbide tipped
SPECIFICATIONS
Metric
| Order No. | Range (mm) |
Graduation (mm) |
Measuring force (N) |
Maximum permissible error J MPE (µm) |
Flatness (µm) |
Parallelism (µm) |
Constant measuring force |
| 102-301 | 0 - 25 | 0.01 | 5 - 10 | ±2 | 0.6 | 2 | Ratchet stop |
| 102-302 | 25 - 50 | ||||||
| 102-303 | 50 - 75 | ||||||
| 102-304 | 75 - 100 | ±3 | 3 |
Metric ___ With vernier scale
| Order No. | Range (mm) |
Graduation (mm) |
Measuring force (N) |
Maximum permissible error J MPE (µm) |
Flatness (µm) |
Parallelism (µm) |
Constant measuring force |
| 102-311 | 0 - 25 | 0.001 | 5 - 10 | ±1 | 0.3 | 1 | Ratchet stop |
| 102-313 | Friction thimble | ||||||
| 102-312 | 25 - 50 | ±2 | Ratchet stop |
Metric ___ Micrometer set
| Order No. | Range (mm) |
Models included |
| 102-911-40 | 0 - 100 (Four micrometers per set) |
• 102-301 102-302 102-303 102-304 • 3 micrometer standards |
• Standard accessories: Setting standard, 1 pc. (except for measuring range 0 to 25 mm models)
Spanner
(301336), 1 pc. (for measuring range 0 to 25 mm/25 to 50 mm models)
Spanner (200877), 1 pc. (for measuring
range 50 to 75 mm/75 to 100 mm models)
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Digital/Analog | Analog |
| Range (mm) | L | a | b | c |
| 0 - 25 | 0 | 5 | 26 | 2.5 |
| 25 - 50 | 25 | 7.8 | 32 | 2.5 |
| 50 - 75 | 50 | 10.6 | 45 | 2.5 |
| 75 - 100 | 75 | 11 | 58 | 2.5 |
