Standard Dial Gauges - 0.01 mm
Dial Gauges are widely used manufacturing plants.
● The stem, made of SK quench hardened with strength, is malfunction-free due to fastening.
● The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle.
● The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction.
● The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way.
● Jeweled bearing is installed to our general Dial Gauges.
Specifications
(unit: μm)
| Order No. | Graduation (mm) |
Range (mm) | Reading | Indication error (MPE) | Hysteresis error |
Repeatability | Measuring force less than (N) |
|||
| 1/10 revolution | 1/2 revolution | One revolution | Whole measuring range |
|||||||
| 107-HG | 0.01 | 10 | ±0 - 50 - 100 | 4 | 7 | 8 | 12 | 2.5 | 3 | 1.4 |
| 107-DX | 0.01 | 10 | ±0 - 50 - 100 | 5 | 9 | 10 | 15 | 3 | 3 | 1.4 |
| 107 | 0.01 | 10 | ±0 - 50 - 100 | 5 | 9 | 10 | 15 | 3 | 3 | 1.4 |
| 107F | 0.01 | 10 | ±0 - 50 - 100 | 5 | 9 | 10 | 15 | 3 | 3 | 1.4 |
| 107-SWA | 0.01 | 10 | ±0 - 50 - 100 | 5 | 9 | 10 | 15 | 3 | 3 | 1.4 |
| 107-BL | 0.01 | 10 | ±0 - 50 - 100 | 5 | 9 | 10 | 15 | 3 | 3 | 1.4 |
| 107F-RE | 0.01 | 10 | ±0 - 50 - 100 | 5 | 9 | 10 | 15 | 3 | 3 | 1.4 |
| 107-LL | 0.01 | 10 | ±0 - 50 - 100 | 5 | 9 | 10 | 15 | 3 | 3 | 1.4 |
| 107W | 0.01 | 10 | ±0 - 50 - 100 | 5 | 9 | 10 | 15 | 3 | 3 | 1.4 |
| 107F-T | 0.01 | 10 | ±100 - 50 - 0 | 5 | 9 | 10 | 15 | 3 | 3 | 1.4 |
| 107-E | 0.01 | 10 | ±0 - 50 - 100 | 5 | 9 | 10 | 15 | 3 | 3 | initial pressure1.4 |
| 17 | 0.01 | 1 | 0 - 50 - 0 | 5 | 8 | 8 | 8 | 3 | 4 | 1.4 |
| 57-SWA | 0.01 | 5 | ±0 - 50 - 100 | 5 | 9 | 10 | 12 | 3 | 3 | 1.4 |
| 57 | 0.01 | 5 | ±0 - 50 - 100 | 5 | 9 | 10 | 12 | 3 | 3 | 1.4 |
| 57F | 0.01 | 5 | ±0 - 50 - 100 | 5 | 9 | 10 | 12 | 3 | 3 | 1.4 |
| 57B | 0.01 | 5 | 0 - 50 - 0 | 5 | 9 | 10 | 12 | 3 | 3 | 1.4 |
| แบรนด์สินค้า | PEACOCK |
|---|---|
| Order No. | 107-DX |
| Graduation | 0.01 mm |
Standard 0.01mm
mm
| Order No. | A | B | C | D | E | F | G | H | I | J | |
| 107-HG | 65 | 41.5 | 18.5 | 53 | 14.5 | 20 | 4 | 6.5 | 49 | 8.0 | 0 –0.03 |
| 107-DX | 65 | 50.7 | 17 | 55.7 | 14.5 | 20 | 5 | 7 | 52 | 8.0 | 0 –0.03 |
| 107 | 65 | 41.5 | 18.5 | 53 | 14.5 | 20 | 4 | 6.5 | 49 | 8.0 | 0 –0.03 |
| 107F | 65 | 41.5 | 18.5 | 53 | 14.5 | - | 4 | 6.5 | 49 | 8.0 | 0 –0.03 |
| 107-SWA | 65 | 41.5 | 17.5 | 55 | 15 | 20 | 4 | 6.5 | 49 | 8.0 | 0 –0.03 |
| 107-BL | 65 | 41.5 | 18.5 | 53 | 14.5 | 4 | 6.5 | 49 | 8.0 | 0 –0.03 |
|
| 107F-RE | 65 | 41.5 | 18.5 | 53 | 14.5 | 20 | 4 | 6.5 | 49 | 8.0 | 0 –0.03 |
| 107-LL | 65 | - | 18.5 | 53 | 14.5 | 20 | 4 | 6.5 | 49 | 8.0 | 0 –0.03 |
| 107W | 65 | 41.5 | 17.5 | 55 | 17 | 20 | 4 | 6.5 | 49 | 8.0 | 0 –0.03 |
| 107F-T | 65 | 41.5 | 18.5 | 53 | 14.5 | - | 4 | 6.5 | 49 | 8.0 | 0 –0.03 |
| 107-E | 65 | 41.5 | 18.5 | 53 | 14.5 | 20 | 4 | 6.5 | 49 | 8.0 | 0 –0.03 |
| 17 | 65 | 41.5 | 18.5 | 53 | 14.5 | 20 | 4 | 6.5 | 49 | 8.0 | 0 –0.03 |
| 57-SWA | 65 | 41.5 | 18.5 | 55 | 15 | 20 | 4 | 6.5 | 49 | 8.0 | 0 –0.03 |
| 57 | 65 | 41.5 | 18.5 | 53 | 14.5 | 20 | 4 | 6.5 | 49 | 8.0 | 0 –0.03 |
| 57F | 65 | 41.5 | 18.5 | 53 | 14.5 | - | 4 | 6.5 | 49 | 8.0 | 0 –0.03 |
| 57B | 65 | 41.5 | 18.5 | 53 | 14.5 | - | 4 | 6.5 | 49 | 8.0 | 0 –0.03 |
