112-213 | Point Micrometers SERIES 112 - With carbide tip | MITUTOYO
ราคาพิเศษ
THB 0.00
ราคาปรกติ
THB 2,497.20
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
112-213
QTY:
10
• Pointed spindle and anvil for measuring the web thickness of drills, small grooves, keyways, and other hard-to-reach dimensions.
• The measuring points have approximately 0.3 mm radius.
• Carbide measuring tips are also available.
• Equipped with Ratchet Stop for constant measuring force.
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Inch-Metric | Metric |
| Digital/Analog | Analog |
| Order No. | 112-213 (CPM30-25W) |
| Range | 0 - 25 mm |
| Graduation | 0.01 mm |
| Point | 30º |
| Order No. | L | a | b | c | Frame thickness |
| 112-153 | 0 | 10 | 38 | 12.5 | (9) |
| 112-154 | 25 | 12 | 49 | (10) | |
| 112-155 | 50 | 14 | 60 | (11) | |
| 112-156 | 75 | 16.7 | 79 | 15.3 | (13) |
