133-171 | Tubular Inside Micrometers SERIES 133 — Single-Rod Type | MITUTOYO
ราคาพิเศษ
THB 0.00
ราคาปรกติ
THB 3,603.74
*ราคายังไม่รวม VAT
สินค้าหมด
SKU
133-171
QTY:
0
• Standard Single-rod Type inside micrometer.
• Carbide-tipped measuring faces.
• A reference gage is necessary for reference point setting.
• An optional reference gage, such as Gauge Block Accessory Set, CERA inside Micro Checker or a setting ring, is required for accurately setting the micrometer before measuring.
SPECIFICATIONS
Metric ___ Individual
| Order No. | Range (mm) | Graduation (mm) | Maximum permissible error J MPE (μm) |
| 133-145 | 100 -125 | 0.01 | ±5 |
| 133-146 | 125 - 150 | ||
| 133-147 | 150 - 175 | ||
| 133-148 | 175 - 200 | ||
| 133-149 | 200 - 225 | ||
| 133-150 | 225 - 250 | ±6 | |
| 133-151 | 250 - 275 | ||
| 133-152 | 275 - 300 | ||
| 133-153 | 300 - 325 | ±7 | |
| 133-154 | 325 - 350 | ||
| 133-155 | 350 - 375 | ||
| 133-156 | 375 - 400 | ±8 | |
| 133-157 | 400 - 425 | ||
| 133-158 | 425 - 450 | ||
| 133-159 | 450 - 475 | ±9 | |
| 133-160 | 475 - 500 | ||
| 133-161 | 500 - 525 | ||
| 133-162 | 525 - 550 | ±10 | |
| 133-163 | 550 - 575 | ||
| 133-164 | 575 - 600 | ||
| 133-165 | 600 - 625 | ±11 | |
| 133-166 | 625 - 650 | ||
| 133-167 | 650 - 675 | ||
| 133-168 | 675 - 700 | ±12 | |
| 133-169 | 700 - 725 | ||
| 133-170 | 725 - 750 | ||
| 133-171 | 750 - 775 | ±13 | |
| 133-172 | 775 - 800 | ||
| 133-173 | 800 - 825 | ||
| 133-174 | 825 - 850 | ±14 | |
| 133-175 | 850 - 875 | ||
| 133-176 | 875 - 900 | ||
| 133-177 | 900 - 925 | ±15 | |
| 133-178 | 925 - 950 | ||
| 133-179 | 950 - 975 | ||
| 133-180 | 975 - 1000 | ±16 |
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Inch-Metric | Metric |
| Digital/Analog | Analog |
| Order no. | 133-171 (IM-775) |
| Range | 750 - 775 mm |
| Graduation | 0.01 mm |
| Maximum permissible error J MPE | ±13 μm |
| Order No. | L1 | L6 | L7 |
| 133-145 | 100 | 5 | 3 |
| 133-146 | 125 | 5 | 3 |
| 133-147 | 150 | 18 | 15 |
| 133-148 | 175 | 18 | 15 |
|
133-149 | | | 133-180 |
200 | | | 975 |
18 | | | 18 |
15 | | | 15 |
