153-301 | Micrometer Heads SERIES 153 — High Accuracy and Resolution | MITUTOYO
ราคาพิเศษ
THB 0.00
THB 0.00
ราคาปรกติ
THB 27,073.14
สินค้าหมด
SKU
153-301
• Fine graduation and high accuracy model, suitable for inspection equipment.
• Non-rotating spindle type.
SPECIFICATIONS
Metric
| Order No. | Range | Graduation | Graduation features |
Stem dia. | Stem | Spindle end | Spindle pitch | Maximum permissible error J MPE* |
| 153-301 | 0 - 25 mm | 0.0005 mm (vernier) |
Bidirectional | 18 mm | Plain | Flat (carbide tip) | 0.5 mm | ±1/±0.5 μm |
• Measuring face: Material / Carbide tip, Hardness /90 HRA or more, Lapped
• Scale finishing: White anodized aluminum
* Wide range/narrow range
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Order No. | 153-301 (MHP-25V) |
| range of Micrometer head | 0 - 25 mm |
| Graduation | 0.0005 mm (vernier) |
| Graduation features | Bidirectional |
| Stem dia. | 18 mm |
| Stem | Plain |
| Spindle end | Flat (carbide tip) |
| Spindle pitch | 0.5 mm |
| Maximum permissible error J MPE | ±1/±0.5 μm |
