170-102-12 | SERIES 170 — UDT-2 Calibration Tester | MITUTOYO
THB 0.00
THB 0.00
พร้อมส่ง
SKU
170-102-12
• UDT-2 is an accuracy tester for 0.01 mm resolution/graduation dial indicators, dial test indicators and bore gages.
• With the optional stand, inspection of dial bore gages becomes possible.
• Measuring range: 0 to 25 mm. Accepts ø6 mm, ø8 mm, 1/4 in and 3/8 in indicator stems.
| Order No. | Micrometer head | Accuracy (µm) | ||
| Graduation (mm) |
Range (mm) |
Feed accuracy (25 mm stroke) |
Hysteresis | |
| 170-102-12 | 0.001 | 0 - 25 | ±2 | 0.5 |
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Micrometer head - Graduation | 0.001 mm |
| Micrometer head - Range | 0 - 25 mm |
| Accuracy - Feed accuracy (25 mm stroke) | ±2 µm |
| Accuracy - Hysteresis | 0.5 µm |
