SERIES 293 | Digimatic Outside Micrometers | MITUTOYO
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 5,713.80
พร้อมส่ง
SKU
1MIT-MDC-SX
• Simple design with no data output for accuracy at a lower cost.
• Provided only with an origin-set button for easy origin setting.
• Extended battery life of approximately 2.4 years, which helps reduce the number of battery replacements required.
• Equipped with Ratchet Stop for constant measuring force.
• Measuring faces: Carbide tipped
SPECIFICATIONS
Metric ____ With ratchet stop
| Order No. | Range (mm) | Resolution (mm) | Measuring force (N) |
Maximum permissible error J MPE (µm) |
Flatness (µm) |
Parallelism (µm) |
Mass (g) |
| Without SPC data output | |||||||
| 293-821-30 | 0 - 25 | 0.001 | 5 - 10 | ±2 | 0.3 | 2 | 270 |
Inch / Metric ___ With ratchet stop
| Order No. | Range (in) | Resolution | Measuring force (N) |
Maximum permissible error J MPE (in) |
Flatness (in) |
Parallelism (in) |
Mass (g) |
| Without SPC data output | |||||||
| 293-831-30 | 0 - 1 | 0.00005 in/0.001 mm | 5 - 10 | ±0.0001 | 0.000012 | 0.00008 | 270 |
Inch / Metric ___ With friction thimble
| Order No. | Range (in) | Resolution | Measuring force (N) |
Maximum permissible error J MPE (in) |
Flatness (in) |
Parallelism (in) |
Mass (g) |
| Without SPC data output | |||||||
| 293-832-30 | 0 - 1 | 0.00005 in/0.001 mm | 5 - 10 | ±0.0001 | 0.000012 | 0.00008 | 270 |
• Power source: SR44 battery (1 pc.), 938882 included as standard (for operational checks)
• Battery life: Approx.
2.4 years under normal use
• Position detection method: Electromagnetic rotary sensor
• Spanner (301336), 1
pc.
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Digital/Analog | Digital |
