340-352-30 | Outside Micrometers SERIES 340 — with Interchangeable Anvils | MITUTOYO
ราคาพิเศษ
THB 0.00
ราคาปรกติ
THB 14,757.01
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
340-352-30
QTY:
4
• Wide measuring range with interchangeable anvils.
• Measuring face of the spindle is carbide tipped (standard model).
• Wide measuring range with interchangeable anvils.
• Measuring face of the spindle is carbide tipped (standard model).
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Digital/Analog | Digital |
| Inch-Metric | Inch/Metric |
| Order No. | 340-352-30 (OMC-12"MX) |
| Range | 6 - 12 in |
| Resolution | 0.0001 in/ 0.001 mm |
| Spindle feed error | 0.00015 in |
| Flatness | 0.000024 in |
| Parallelism | 0.0002 in |
| Interchangeable anvils | 6 pcs. |
| Setting Standard - Qty | 6 |
| Setting Standard - Size | 6 - 11 in |
| Micrometer head stroke | 1 in |
| L: Range (mm) | b | |||||
| Range | 300 - 400 mm models | 300 - 325 | 325 - 350 | 350 - 375 | 375-400 | 224 |
| Range | 400 - 500 mm models | 400 - 425 | 425 - 450 | 450 - 475 | 475 - 500 | 273 |
| Range | 500 - 600 mm models | 500 - 525 | 525 - 550 | 550 - 575 | 575 - 600 | 332 |
| Range | 600 - 700 mm models | 600 - 625 | 625 - 650 | 650 - 675 | 675 - 700 | 382 |
| Range | 700 - 800 mm models | 700 - 725 | 725 - 750 | 750 - 775 | 775 - 800 | 430 |
| Range | 800 - 900 mm models | 800 - 825 | 825 - 850 | 850 - 875 | 875 - 900 | 480 |
| Range | 900 - 1000 mm models | 900 - 925 | 925 - 950 | 950 - 975 | 975 - 1000 | 530 |
| Order No. | 304001 | 304002 | 304003 | 304004 | ||
| c: Overall (mm) | 87 | 62 | 37 | 12 | ||
| Interchangeable anvil | M3 | M4 | M5 | M6 | ||
