350-281-30 | Digimatic Micrometer Heads SERIES 350 | MITUTOYO
ราคาพิเศษ
THB 0.00
ราคาปรกติ
THB 4,698.13
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
350-281-30
QTY:
3
• Easy-to-read digital display.
• All models support data output.
SPECIFICATIONS
Metric
| Order No. | Range (mm) |
Resolution (mm) |
Graduation (mm) |
Stem | Stem dia. (mm) |
Spindle end | Graduation features |
Maximum permissible error J MPE (μm) |
| 164-163 | 0 - 50 | 0.001 | — | Plain | 18 | Flat (carbide tip) | — | ±3 |
| 350-251-30* | 0 - 25 | 0.01 | 10 | Standard | ±2 | |||
| 350-252-30* | W/clamp nut | |||||||
| 350-253-30* | Plain | Spherical (SR4) (carbide tip) |
||||||
| 350-254-30* | W/clamp nut | |||||||
| 350-281-30** | Plain | 12 | Flat (carbide tip) | |||||
| 350-282-30** | W/clamp nut | |||||||
| 350-283-30** | Plain | Spherical (SR4) (carbide tip) |
||||||
| 350-284-30** | W/clamp nut | |||||||
| 350-261-30** | Plain | Flat | ||||||
| 350-271-30** | ||||||||
| 350-272-30* | W/clamp nut | |||||||
| 350-273-30** | Plain | Spherical (SR4) (carbide tip) |
||||||
| 350-274-30* | W/clamp nut |
Power source for series 350: SR44 battery (1 pc.), 938882 included as standard (for operational checks)
Power source for series 164: SR44 battery (2 pcs.), 938882 included as standard (for operational checks)
• Battery life:
Approx. 2.4 years under normal use (for 350-XXX)
Approx. 1.8 years under normal use (for 164-163, 164)
• Measuring face: Material / Carbide tip, Hardness / 90 HRA or more, Lapped
• Scale finishing: Satin-chrome plated
* These models are not water-proof.
** IP65 dust / water protection type. Stem diameter of IP65 type is 12 mm.
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Digital/Analog | Digital |
| Inch-Metric | Metric |
| Order No. Micro Head | 350-281-30 (MHN1-25MX(IP65)) |
| Range | 0 - 25 mm |
| Resolution | 0.001 mm |
| Graduation | 0.01 mm |
| Stem | Plain |
| Stem dia. | 12 mm |
| Spindle end | Flat (carbide tip) |
| Graduation features | Standard |
| Maximum permissible error J MPE | ±2 μm |
