523-123 | Dial Snap Meters SERIES 523 | MITUTOYO
ราคาพิเศษ
THB 0.00
ราคาปรกติ
THB 10,588.79
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
523-123
QTY:
20
• The snap meter with a built-in dial indicator enables accurate Go/No-go judgement without interruption. Pushing the retractable anvil button causes the anvil and pointer to move, enabling speedy measuremets.
• Designed for use with a stand to enable a more stable measurement.
• Greatly improved accuracy: indication accuracy and graduation of 1 μm.
• IP protection level: 54, coolant-splash resistant during grinding process.
• Hard-coated crystal: enhanced oil and scratch resistance.
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Inch-Metric | Metric |
| Digital/Analog | Dial |
| Order No. | 523-122 (PSM-50R) |
| Range | 50 - 75 mm |
| Dial graduation | 0.001 mm |
| Measuring force (N) | 5 - 10 |
| Flatness | 0.3 µm |
| Parallelism | 0.6 µm |
| Dispersion of indication | 0.4 µm |
| Dial indication accuracy | 1 µm |
| Indicating range | ±0.06 mm |
| Mass | 950 g |
| Range (mm) | b | d |
| 0 - 25 | 25 | 31 |
| 25 - 50 | 35 | 56 |
| 50 - 75 | 47 | 81 |
| 75 - 100 | 60 | 106 |
