523-142 | Snap Meters SERIES 523 | MITUTOYO
ราคาพิเศษ
THB 0.00
ราคาปรกติ
THB 9,173.83
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
523-142
QTY:
7
• The snap meter with an external indicator enables accurate Go/No-go judgement without interruption. Pushing the retractable anvil button causes the anvil and pointer to move, enabling speedy measuremets.
• Select your preferred indicator. The measurement result can be externally output using an indicator with an output function.
• Measuring faces: Carbide tipped
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Inch-Metric | Metric |
| Digital/Analog | Analog |
| Order No. | 523-142 (PSM-50S) |
| Range | 25 - 50 mm |
| Anvil movement | 2 mm |
| Measuring force (N) | 5 - 10 |
| Repeatability of indication | 0.4 μm |
| Flatness | 0.3 µm |
| Parallelism | 0.6 µm |
| Mass | 810 g |
| Range (mm) | b | d |
| 0 - 25 | 25 | 31 |
| 25 - 50 | 35 | 56 |
| 50 - 75 | 47 | 81 |
| 75 - 100 | 60 | 106 |
