SERIES 533 | Vernier Caliper Nib Style and Standard Jaws | Mitutoyo
สินค้าหมด
SKU
1MIT-VCNSSJ-533
• Allows inside and outside measurements directly from the upper and lower Vernier scales.
• Main scale and Vernier scale with a satin chrome finish provides better readability.
SPECIFICATIONS
Metric
| Code No. | Range (mm)*1 | Resolution (mm) |
Maximum permissible error (mm)*2 | Remarks | |
| E MPE | S MPE | ||||
| 533-404 | 0 - 500 (20.1 - 520) | 0.05 | ±0.10 | ±0.10 | — |
| 533-405 | 0 - 750 (20.1 - 770) | ±0.12 | ±0.12 | ||
| 533-406 | 0 - 1000 (20.1 - 1020) | ±0.15 | ±0.15 | ||
| 533-504 | 0 - 500 (20.1 - 520) | 0.02 | ±0.05 | ±0.05 | with fine adjustment |
| 533-505 | 0 - 750 (20.1 - 770) | ±0.06 | ±0.06 | ||
| 533-506 | 0 - 1000 (20.1 - 1020) | ±0.07 | ±0.07 | ||
*1 ( ): Inside measurement
*2 The Partial Surface Contact Error (E MPE) and Shift Error (S MPE) are terms defined by ISO 13385-1:2019.
