534-101 | Long Jaw Vernier Caliper SERIES 534 | MITUTOYO
ราคาพิเศษ
THB 0.00
THB 0.00
ราคาปรกติ
THB 12,305.00
พร้อมส่ง
SKU
534-101
These vernier calipers with long jaws come with or without fine adjustment and let you measure hard-to-reach features.
They offer you the following benefits:
- Long jaws enable you to measure hard-to-reach workpiece features.
- The top offset vernier scale allows you to directly read the inside dimensions without having to add the jaw blade width.
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Range | 0 - 12 in / 0 - 300 mm |
| Maximum permissible error E MPE | ±0.07 mm/ ±0.5/128 in |
| Maximum permissible error S MPE | ±0.07 mm/ ±0.5/128 in |
| Remarks | +10 mm/0.394 in to reading in inside measurement without fine adjustment |
| Note | *1 ( ): Minimum dimension in ID measurement *2 The Partial Surface Contact Error (E MPE) and Shift Error (S MPE) are terms defined by ISO 13385-1:2019. |
