536-101 | Offset Caliper SERIES 536 — Vernier Type | MITUTOYO
ราคาพิเศษ
THB 0.00
ราคาปรกติ
THB 3,997.20
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
536-101
QTY:
4
• The beam-mounted jaw can be adjusted to facilitate measurement of stepped sections.
SPECIFICATIONS
Metric ___ Analog model
| Order No. | Range (mm) | Graduation (mm) | Maximum permissible error (mm)* | |
| E MPE | S MPE | |||
| 536-101 | 0 - 150 | 0.05 | ±0.05 | ±0.07 |
| 536-102 | 0 - 150 | |||
| 536-103 | 0 - 200 | ±0.08 | ±0.10 | |
* The Partial Surface Contact Error (E MPE) and Shift Error (S MPE) are terms defined by ISO 13385-1:2019.
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Inch-Metric | Metric |
| Order No. | 536-101 (NT10-15) |
| Range | 0 - 150 mm |
| Graduation | 0.05 mm |
| Maximum permissible error E MPE | ±0.05 mm |
| Maximum permissible error S MPE | ±0.07 mm |
| Order No. | Model | Range (mm) | A | B | C | D | G | H | N | W | T |
| 536-101 | Analog model | 0 - 150 | 17 | 21.5 | 17 | 40 | 10 | 16 | (18) | 95 | 3 |
| 536-102 | 0 - 200 | 20.5 | 25 | 20.5 | 50 | (4) | |||||
| 536-103 | 0 - 300 | 22 | 27.5 | 22 | 64 | 15 | 20 | (23.5) | 135 | 3.8 |
