543-853E | High-performance ABS Digimatic Indicator ID-FNX (Digimatic S1 supported) SERIES 543 — with Back-lit LCD Screen | MITUTOYO

• ID-F Series is a next-generation indicator with various new functions, supporting bidirectional communication. With the addition of the appropriate data cable and software, remote zero setting and gage setting can all be implemented from a connected PC, thereby improving your work efficiency.

• This series adopts an external power supply to operate a bright backlit display. The display color helps you make tolerance judgment at a glance.

Green indication for GO judgment	Red indication for ±NG judgment

• The next calibration due date can be set with an alarm to improve instrument management.

• The ABS (ABSOLUTE) scale restores the last origin position* automatically when the indicator is turned on, and realizes high reliability by eliminating over-speed errors.

Functions
• Peak detection (MAX/MIN)
• Runout range measurement (MAX - MIN)
  Note: Peak detection
   1) Sampling rate:
        Resolution 0.0005 mm 50 readings/s
        Resolution 0.001 mm, 0.01 mm 500 readings/s
   2) Capturing speed:
        Resolution 0.0005 mm 50 μm/s
        Resolution 0.001 mm, 0.01 mm 500 μm/s
• Zero-setting (INC system)
• Presetting (ABS system)
• Measuring direction switching
• Tolerance judgment
• Resolution switching
• Simple calculation f(x) =Ax
• Analog resolution selection
• Data hold (when not connected to an external device)
• Function Lock
• Calibration schedule warning
• Data output
• Display rotation (330°)
• Error alarm display
