High-performance ABS Digimatic Indicator ID-FNX (Digimatic S1 supported) SERIES 543 — with Back-lit LCD Screen | MITUTOYO
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 17,697.80
พร้อมส่ง
SKU
ID-FNX
• ID-F Series is a next-generation indicator with various new functions, supporting bidirectional communication. With the addition of the appropriate data cable and software, remote zero setting and gage setting can all be implemented from a connected PC, thereby improving your work efficiency.
• This series adopts an external power supply to operate a bright backlit display. The display color helps you make tolerance judgment at a glance.
| Green indication for GO judgment | Red indication for ±NG judgment |
 |
 |
• The next calibration due date can be set with an alarm to improve instrument management.
• The ABS (ABSOLUTE) scale restores the last origin position* automatically when the indicator is turned on, and realizes high reliability by eliminating over-speed errors.
SPECIFICATIONS
Metric ----- ISO/JIS Type
| Order No. | Range (mm) | Resolution (mm) |
Maximum permissible error (MPE)*1 (mm) | Maximum permissible limit (MPL) |
Power source |
Mass Partial measuring (g) |
|||
| Partial measuring range P MPE |
Total measuring range E MPE |
Hysteresis H MPE |
Repeatability R MPE |
Measuring force (N) | |||||
| 543-855 | 12.7 | 0.0005/ 0.001/0.01 (selectable) |
0.0025 | 0.0025 | 0.002 | 0.002 | 1.5 or less | AC adapter (5.9 V) |
180 |
| 543-855B (flat back) |
170 | ||||||||
| 543-851 | 25.4 | 1.8 or less | 240 | ||||||
| 543-853 | 50.8 | 0.004 | 0.004 | 2.3 or less | 330 | ||||
| 543-857 | 0.003 | 0.003 | |||||||
Inch / Metric ----- ASME/ANSI /AGD Type
| Order No. | Range (mm) | Resolution (mm) |
Maximum permissible error (MPE)*1 (mm) | Maximum permissible limit (MPL) |
Power source |
Mass Partial measuring (g) |
||
| Overall*2 | Hysteresis | Repeatability | Measuring force (N) | |||||
| 543-856 | 0.5 in/ 12.7 mm |
0.00002/ 0.00005/ 0.0001/ 0.0005/ 0.001 in, 0.005/ 0.001/ 0.01 mm (selectable) |
±0.00010 | 0.00008 | 0.00008 | 1.5 or less | AC adapter (5.9 V) |
200 |
| 543-856B (flat back) |
170 | |||||||
| 543-852 | 1 in/ 25.4 mm |
1.8 or less | 240 | |||||
| 543-854 | 2 in/ 50.8 mm |
±0.00016 | 2.3 or less | 330 | ||||
| 543-858 | ±0.00012 | |||||||
• Display: 7-digit display, sign, and analog bar with 2-color backlight
• Response speed: Unlimited
*1 These values apply to normal measurements at 20 °C.
*2 Overall magnification and linearity
*3 To denote your AC power cable add the following suffixes to the code No.: A for UL / CSA and PSE, D for CEE, DC for
CCC, E for BS, K for KC, No suffix is required for JIS/100 V.
