High Accuracy Type (Resolution: 0.0005 mm)
• Thickness gages can quickly measure the thickness of thin products such as paper and felt.
• Using a ceramic contact and anvil, there is no need to worry about rust. (except for 547-401A)
Metric
| Order No. | Resolution (mm) |
Range (mm) |
Measuring depth (mm) |
Contact point, Anvil (mm) |
Parallelism of Contact point, Anvil (μm) |
Accuracy (μm) |
Measuring force (N) |
Mass (g) |
Remarks |
| 547-401A | 0.0005 (0.001/0.01 selectable) |
0 - 12 | 21 | ø6.3 Flat (Carbide) | 3 | ±3 | 3.5 or less | 275 | High accuracy, carbide point anvil |
Inch / Metric
| Order No. | Resolution | Range (in) |
Measuring depth | Contact point, Anvil | Parallelism of Contact point, Anvil |
Accuracy | Measuring force (N) |
Mass (g) |
Remarks |
| 547-400A | 0.00002/0.00005/ 0.0001/0.0005 in 0.0005/0.001/ 0.01 mm (selectable) |
0 - 0.47 | 21 mm (0.83 in) | ø6.3 mm (ø0.25 in) Flat | 0.0001 in/0.003 mm | ±0.00012 in/±3 μm | 3.5 or less | 275 | High accuracy, carbide point anvil |
| แบรนด์สินค้า | MITUTOYO |
|---|
