7301A | Thickness Gages Series 7 - Standard Type (Graduation: 0.01 mm) | MITUTOYO
ราคาพิเศษ
THB 0.00
ราคาปรกติ
THB 1,538.32
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
7301A
QTY:
5
Standard Type (Graduation: 0.01 mm)
• Integrated moulding of the bezel and crystal ensures protection against water and oil penetration via the front face.
Metric
| Order No. | Graduation (mm) |
Range (mm) |
Measuring depth (mm) |
Contact point, Anvil (mm) |
Parallelism of Contact point, Anvil (μm) |
Accuracy (μm) |
Measuring force (N) |
Mass (g) |
Remarks |
| 7327A | 0.001 | 0 - 1 | 30 | ø10 Flat | 5 | ±5 | 1.5 or less | 225 | Fine dial reading, ceramic point / anvil |
| 7301A | 0.01 | 0 - 10 | 30 | ø10 Flat | 5 | ±15 | 1.4 or less | 205 | Standard, ceramic point / anvil |
| 7305A | 0.01 | 0 - 20 | 30 | ø10 Flat | 5 | ±20 | 2.0 or less | 220 | Standard, ceramic point / anvil |
| 7321A | 0.01 | 0 - 10 | 120 | ø10 Flat | 5 | ±15 | 1.4 or less | 370 | Deep throat, ceramic point / anvil |
| 7323A | 0.01 | 0 - 20 | 120 | ø10 Flat | 5 | ±20 | 2.0 or less | 370 | Deep throat, ceramic point / anvil |
Note: The dial indicator needs to be reset when a contact point is replaced.
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Thickness Gages_7 | 7301A |
| Inch-Metric | Metric |
| Graduation | 0.001 mm |
| Range | 0 - 10 mm |
| Measuring depth | 30 mm |
| Contact point, Anvil | ø10 Flat mm |
| Parallelism of Contact point, Anvil | 5 μm |
| Accuracy | ±15 μm |
| Measuring force (N) | 1.4 or less |
| Remarks | Standard, ceramic point / anvil |
