7315A |Blade thickness measurement | MITUTOYO
ราคาพิเศษ
THB 0.00
THB 0.00
ราคาปรกติ
THB 3,310.58
พร้อมส่ง
SKU
7315A
Blade thickness measurement
• Measuring faces of the contact point and anvil are blade-shaped (thickness: 1 mm). Suitable for measuring narrow grooves.
Metric
| Order No. | Resolution (mm) |
Range (mm) |
Measuring depth (mm) |
Contact point, Anvil (mm) |
Parallelism of Contact point, Anvil (μm) |
Accuracy (μm) |
Measuring force (N) |
Mass (g) |
Remarks |
| 7315A | 0.01 | 0 - 10 | 30 | t=1 Blade | 5 | ±15 | 1.4 or less | 220 | Blade thickness |
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Thickness Gages_7 | 7315A |
| Inch-Metric | Metric |
| Graduation | 0.01 mm |
| Range | 0 - 10 mm |
| Measuring depth | 30 mm |
| Contact point, Anvil | t=1 Blade |
| Parallelism of Contact point, Anvil | 5 μm |
| Accuracy | ±15 μm |
| Measuring force (N) | 1.4 or less |
| Remarks | Blade thickness |
