ABSOLUTE Digimatic Depth Gage SERIES 547 | MITUTOYO
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 14,909.38
พร้อมส่ง
SKU
1MIT-DG-ICD
• Easy-to-read digital display effectively prevents misreading.
• An analog bar indicator on the LCD is convenient for observing subtle movements such as the approach to tolerance.
• Data output function allows integration into statistical process control and measurement systems.
Functions
• Peak detection (MAX/MIN)
• Runout range measurement (MAX - MIN)
• Zero-setting (INC system)
• Presetting (ABS system)
• Measuring direction switching
• Tolerance judgment
• Resolution switching (For 0.0005 mm or 0.00002 inch resolution type)
• Simple calculation: f(x) =Ax
• Function Lock
• Calibration schedule warning
• Auto power OFF
• Data output
• Display value holding (when no external device is connected)
• 330° rotary display
• Low battery / voltage alarm display
• Error alarm display
SPECIFICATIONS
Metric
| Order No. | Range (mm) |
Resolution (mm) |
Stroke (mm) |
Accuracy (μm) |
Measuring force (N) |
Base | ||
| W (mm) | T (mm) | flatness (μm) | ||||||
| 547-211A | 0 - 200 | 0.01 | 12.7 | ±20 | 1.5 or less | 63.5 | 16 | 5 |
| 547-212A | 101.6 | |||||||
| 547-251A | 0.0005 (0.001/0.01 mm selectable) |
±5 | 63.5 | 2 | ||||
| 547-252A | 101.6 | |||||||
| Order No. | Contact point* | Extension rod* | Indicator* |
| 547-211A | Provided with a carbide-tipped ball point (21JAA224) |
5 pcs. (10, 20, 30, 30, 100 mm) |
543-710B |
| 547-212A | |||
| 547-251A | 543-700B | ||
| 547-252A |
Inch / Metric
| Order No. | Range (in) |
Resolution | Stroke (in) |
Accuracy (in) |
Measuring force (N) |
Base | ||
| W (in) | T (in) | flatness (in) | ||||||
| 547-217A | 0 - 8 | 0.0005 in/0.01 mm | 0.5 | ±0.001 | 1.5 or less | 2.5 | 0.63 | 0.0002 |
| 547-218A | 4 | |||||||
| 547-257A | 0.00002 in (0.00005/0.0001/0.0005 in 0.0005/0.001/0.01 mm selectable) |
±0.0002 | 2.5 | 0.00008 | ||||
| 547-258A | 4 | |||||||
| Order No. | Contact point* | Extension rod* | Indicator* |
| 547-217A | Provided with a carbide-tipped ball point (21JZA242) |
4 pcs. (0.5 in, 1 in, 2 in, 4 in) |
543-712B |
| 547-218A | |||
| 547-257A | 543-702B | ||
| 547-258A |
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Digital/Analog | Digital |
