• New standard model which features a prismatic column and offers excellent rigidity and accuracy.
• Allows smooth elevation by the slider adjustment wheel. • U-WAVE-T/TC/TCB (wireless data transmitter) can be installed on the back of the display unit.
Functions
• Origin-setting: Any convenient reference surface, such as a surface plate, etc., can be stored as the ABSOLUTE origin point.
• ABSOLUTE measurement: After power is turned ON, measurement can be started without zero-setting if origin-setting was previously performed. ABSOLUTE origin position can be changed by ORIGIN button.
• Incremental measurement: Allows origin setting at any arbitrary position. In this case, the origin point is not stored after turning off the power.
• Data hold Display value can be held.
• Data output: Allows integration into statistical process control and measurement systems. (Refer to page 09-3.)
• Low-voltage alert: Low-voltage alert: If the battery voltage becomes low, a “B” appears in the display to alert the user before measurement is no longer possible so that the battery can be changed in good time.
SPECIFICATIONS
Metric
Order No. | Range (mm) | Resolution (mm) | Maximum permissible error E MPE (mm)* |
Response speed | Mass (kg) |
570-402 | 0 - 300 | 0.01 | ±0.03 | Unlimited | 4.6 |
570-404 | 0 - 600 | ±0.05 | 6.4 |
Inch / Metric
Order No. | Range | Resolution | Maximum permissible error E MPE* |
Response speed | Mass (kg) |
570-412 | 0 to 12 in/0 to 300 mm | 0.0005 in/ 0.01 mm |
±0.0015 in/±0.03 mm | Unlimited | 4.6 |
570-413 | 0 to 18 in/0 to 450 mm | ±0.0020 in/±0.05 mm | 5.9 | ||
570-414 | 0 to 24 in/0 to 600 mm | 6.4 |
• Power source: SR44 battery (1 pc.), 938882 included as standard (for operational checks)
• Battery life: Approx. 5 years
* Maximum permissible error, E MPE is the term (notation) used in JIS B 7517: 2018, revised based on ISO/TR 14253-6: 2012.
