ACME SCREW THREAD GAUGES | FUJI TOOL
ราคาต่ำสุด
THB 0.00
พร้อมส่ง
SKU
FUJ-ACME
QTY:
0
Features
A standard for grinding and setting tools when cutting trapezoidal screw threads (Acme threads). The depth of threads are same.
Material : Steel SPCC
Accuracy : ±0.2° (±10’)
For 29° acme thread use(TW)
| Order No. | Model No. | Angle | Type | Size Composition / Contrnts (inch) |
| 03-301 | No.715 | 29° | Round | 1,1 1/3, 2, 3, 4, 5, 6, 7, 8, 9, 10 |
| 03-302 | No.716 | 29° | Square | 1, 1 1/3, 1 1/2, 1 3/4, 2, 2 1/2, 3, 4, 5, 6, 7, 8, 9, 10 |
For 30° acme thread use (TM)
| Order No. | Model No. | Angle | Type | Size Composition / Contrnts (mm) |
| 03-303 | No.717 | 30° | Square | 3, 4, 5, 6, 7, 8, 9, 10 |
| 03-304 | No.718 | 30° | Round | 3, 4, 5, 6, 7, 8, 9, 10 |
For metric trapezoidal thread (Tr)
| Order No. | Model No. | Angle | Type | Size Composition / Contrnts (mm) |
| 03-300 | No.719 | 30° | Square | 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 14 |
| แบรนด์สินค้า | FUJI TOOL |
|---|
