AUSP Rc (Long shank, for Pipe Threads) | Z-PRO Coated Spiral Fluted Taps for Taper Pipe Threads | YAMAWA

ราคาต่ำสุด THB 0.00 ราคาปรกติ THB 2,987.85

พร้อมส่ง

SKU

AUSP Rc (Long shank, for Pipe Threads)

Product Features

Proper tool projection length is secured, achieving a good chip ejection efficiency.
Good internal thread surface and long tool life are achieved through adoption of the unique cutting edge shape and special coating.

Tapping Data

Tapping conditions [AUSP Rc 1/4-19]

Workpiece Materials	SS400
Tapping Speed	5m/min
Machine	Machining center
Holder	With tension and compression
Tapping Fluid	Water soluble cutting fluid

・Compatible with tapping of a wide range of work materials
AUSP Rc　Standard tapping conditions

Workpiece Materials	Standard Tapping Speed（m/min）
Stainless Steels SUS304	〜3
Alloy Steels SCM/SCr	〜5
High Carbon Steels S45C〜	〜7
Medium Carbon Steels S25C〜S45C	〜7
Low Carbon Steels 〜S20C/SS400	〜7
Aluminum Alloy Casting/ Zinc Alloy Casting AC/ADC/ZDC	〜10

Specification

Tapping Speeds depending on Materials

Segment：1G

ข้อมูลเพิ่มเติม
แบรนด์สินค้า	YAMAWA
