Bore Gauge (CN type) for small hole
• These are bore gauges for small holes of which internal diameter is 18.5mm or less and high accuracy measuring is possible as well as standard type bore gauges.
SPECIFICATION
Order No. | Measuring Range (mm) |
Effective Measuring Range (mm) |
Total Range Error(μm) |
Adjacent Error(μm) |
Repeatability (μm) |
Weight (g) |
CN-10 | 6-10 | 0.5 | 5 | 2 | 2 | 70 |
CN-18 | 10-18.5 | 0.6 | 5 | 2 | 2 | 85 |
แบรนด์สินค้า | TECLOCK |
---|
unit : mm
Order No. | A | B | C | D |
CN-10 | 80 | 49 | 5.4 | 4 |
CN-18 | 80 | 100 | 8.5 | 6 |
