CN-10 | BORE GAUGE FOR SMALL HOLE - CN TYPE | TECLOCK
THB 0.00
*ราคายังไม่รวม VAT
สินค้าหมด
SKU
CN-10
QTY:
0
Bore Gauge (CN type) for small hole
• These are bore gauges for small holes of which internal diameter is 18.5mm or less and high accuracy measuring is possible as well as standard type bore gauges.
SPECIFICATION
| Order No. | Measuring Range (mm) |
Effective Measuring Range (mm) |
Total Range Error(μm) |
Adjacent Error(μm) |
Repeatability (μm) |
Weight (g) |
| CN-10 | 6-10 | 0.5 | 5 | 2 | 2 | 70 |
| CN-18 | 10-18.5 | 0.6 | 5 | 2 | 2 | 85 |
| แบรนด์สินค้า | TECLOCK |
|---|---|
| Order No. | CN-10 |
| Measuring Range | 6-10 mm |
unit : mm
| Order No. | A | B | C | D |
| CN-10 | 80 | 49 | 5.4 | 4 |
| CN-18 | 80 | 100 | 8.5 | 6 |
