CPC-S (Metric Threads) | Check Pins for Bored Hole in Thread Cut Tapping (Straight Type) | YAMAWA
ราคาต่ำสุด
THB 0.00
ราคาปรกติ
THB 347.66
พร้อมส่ง
SKU
CPC-S (Metric Threads)
- CPC-S consisting of 5 piece pins enables checking of several kinds of bored hole dia. and checking of depth of bored hole(for cutting taps, straight type).
CPC-S is made from wear resistant HSS material and is applicable for both through hole and blind hole. - There are two types of five-pin set depending on the percentage of thread engagement: one set containing pins of 75% to 65% thread engagements and another containing pins of 100% to 90% thread engagements.
Specification
Segment：7C
|
Size |
Code |
L (mm) |
ℓ (mm) |
d1 (Thread engagement ratio） |
d2 (Thread engagement ratio） |
ℓ1 (mm) |
ℓ2 (mm) |
ℓ3 (mm) |
Ds (mm) |
TYPE |
|
For Metric Threads |
||||||||||
|
M2×0.4 |
CPCS2.0EA |
41.5 |
5.5 |
1.567 (100%) |
1.610 (90%) |
3 |
4 |
5 |
3 |
1 |
|
M2×0.4 |
CPCS2.0EB |
41.5 |
5.5 |
1.589 (95%) |
1.632 (85%) |
3 |
4 |
5 |
3 |
1 |
|
M2×0.4 |
CPCS2.0EC |
41.5 |
5.5 |
1.610 (90%) |
1.654 (80%) |
3 |
4 |
5 |
3 |
1 |
|
M2×0.4 |
CPCS2.0ED |
41.5 |
5.5 |
1.632 (85%) |
1.675 (75%) |
3 |
4 |
5 |
3 |
1 |
|
M2×0.4 |
CPCS2.0EE |
41.5 |
5.5 |
1.654 (80%) |
1.697 (70%) |
3 |
4 |
5 |
3 |
1 |
|
M2×0.4 |
CPCS2.0EF |
41.5 |
5.5 |
1.675 (75%) |
1.719 (65%) |
3 |
4 |
5 |
3 |
1 |
|
M2×0.4 |
CPCS2.0EM |
５ piece set consists of CPCS2.0EB ～ CPCS2.0EF（95%〜65%） |
||||||||
|
M2×0.4 |
CPCS2.0ES |
５ piece set consists of CPCS2.0EA ～ CPCS2.0EE（100%〜70%） |
||||||||
|
M2.5×0.45 |
CPCS2.5FA |
45 |
7.5 |
2.013 (100%) |
2.062 (90%) |
3.75 |
5 |
6.25 |
3 |
1 |
|
M2.5×0.45 |
CPCS2.5FB |
45 |
7.5 |
2.037 (95%) |
2.086 (85%) |
3.75 |
5 |
6.25 |
3 |
1 |
|
M2.5×0.45 |
CPCS2.5FC |
45 |
7.5 |
2.062 (90%) |
2.110 (80%) |
3.75 |
5 |
6.25 |
3 |
1 |
|
M2.5×0.45 |
CPCS2.5FD |
45 |
7.5 |
2.086 (85%) |
2.135 (75%) |
3.75 |
5 |
6.25 |
3 |
1 |
|
M2.5×0.45 |
CPCS2.5FE |
45 |
7.5 |
2.110 (80%) |
2.159 (70%) |
3.75 |
5 |
6.25 |
3 |
1 |
|
M2.5×0.45 |
CPCS2.5FF |
45 |
7.5 |
2.135 (75%) |
2.183 (65%) |
3.75 |
5 |
6.25 |
3 |
1 |
|
M2.5×0.45 |
CPCS2.5FM |
５ piece set consists of CPCS2.5FB ～ CPCS2.5FF（95%〜65%） |
||||||||
|
M2.5×0.45 |
CPCS2.5FS |
５ piece set consists of CPCS2.5FA ～ CPCS2.5FE（100%〜70%） |
||||||||
|
M2.5×0.35 |
CPCS2.5DA |
45 |
7.5 |
2.121 (100%) |
2.159 (90%) |
3.75 |
5 |
6.25 |
3 |
1 |
|
M2.5×0.35 |
CPCS2.5DB |
45 |
7.5 |
2.140 (95%) |
2.178 (85%) |
3.75 |
5 |
6.25 |
3 |
1 |
|
M2.5×0.35 |
CPCS2.5DC |
45 |
7.5 |
2.159 (90%) |
2.197 (80%) |
3.75 |
5 |
6.25 |
3 |
1 |
|
M2.5×0.35 |
CPCS2.5DD |
45 |
7.5 |
2.178 (85%) |
2.216 (75%) |
3.75 |
5 |
6.25 |
3 |
1 |
|
M2.5×0.35 |
CPCS2.5DE |
45 |
7.5 |
2.197 (80%) |
2.235 (70%) |
3.75 |
5 |
6.25 |
3 |
1 |
|
M2.5×0.35 |
CPCS2.5DF |
45 |
7.5 |
2.216 (75%) |
2.254 (65%) |
3.75 |
5 |
6.25 |
3 |
1 |
|
M2.5×0.35 |
CPCS2.5DM |
５ piece set consists of CPCS2.5DB ～ CPCS2.5DF（95%〜65%） |
||||||||
|
M2.5×0.35 |
CPCS2.5DS |
５ piece set consists of CPCS2.5DA ～ CPCS2.5DE（100%〜70%） |
||||||||
|
M3×0.5 |
CPCS3.0GA |
49 |
9 |
2.459 (100%) |
2.513 (90%) |
4.5 |
6 |
7.5 |
4 |
1 |
|
M3×0.5 |
CPCS3.0GB |
49 |
9 |
2.486 (95%) |
2.540 (85%) |
4.5 |
6 |
7.5 |
4 |
1 |
|
M3×0.5 |
CPCS3.0GC |
49 |
9 |
2.513 (90%) |
2.567 (80%) |
4.5 |
6 |
7.5 |
4 |
1 |
|
M3×0.5 |
CPCS3.0GD |
49 |
9 |
2.540 (85%) |
2.594 (75%) |
4.5 |
6 |
7.5 |
4 |
1 |
|
M3×0.5 |
CPCS3.0GE |
49 |
9 |
2.567 (80%) |
2.621 (70%) |
4.5 |
6 |
7.5 |
4 |
1 |
|
M3×0.5 |
CPCS3.0GF |
49 |
9 |
2.594 (75%) |
2.648 (65%) |
4.5 |
6 |
7.5 |
4 |
1 |
|
M3×0.5 |
CPCS3.0GM |
５ piece set consists of CPCS3.0GB ～ CPCS3.0GF（95%〜65%） |
||||||||
|
M3×0.5 |
CPCS3.0GS |
５ piece set consists of CPCS3.0GA ～ CPCS3.0GE（100%〜70%） |
||||||||
|
M3×0.35 |
CPCS3.0DA |
49 |
9 |
2.621 (100%) |
2.659 (90%) |
4.5 |
6 |
7.5 |
4 |
1 |
|
M3×0.35 |
CPCS3.0DB |
49 |
9 |
2.640 (95%) |
2.678 (85%) |
4.5 |
6 |
7.5 |
4 |
1 |
|
M3×0.35 |
CPCS3.0DC |
49 |
9 |
2.659 (90%) |
2.697 (80%) |
4.5 |
6 |
7.5 |
4 |
1 |
|
M3×0.35 |
CPCS3.0DD |
49 |
9 |
2.678 (85%) |
2.716 (75%) |
4.5 |
6 |
7.5 |
4 |
1 |
|
M3×0.35 |
CPCS3.0DE |
49 |
9 |
2.697 (80%) |
2.735 (70%) |
4.5 |
6 |
7.5 |
4 |
1 |
|
M3×0.35 |
CPCS3.0DF |
49 |
9 |
2.716 (75%) |
2.754 (65%) |
4.5 |
6 |
7.5 |
4 |
1 |
|
M3×0.35 |
CPCS3.0DM |
５ piece set consists of CPCS3.0DB ～ CPCS3.0DF（95%〜65%） |
||||||||
|
M3×0.35 |
CPCS3.0DS |
５ piece set consists of CPCS3.0DA ～ CPCS3.0DE（100%〜70%） |
||||||||
|
M3.5×0.6 |
CPCS3.5HA |
57 |
11 |
2.850 (100%) |
2.915 (90%) |
5.25 |
7 |
8.75 |
5 |
1 |
|
M3.5×0.6 |
CPCS3.5HB |
57 |
11 |
2.883 (95%) |
2.948 (85%) |
5.25 |
7 |
8.75 |
5 |
1 |
|
M3.5×0.6 |
CPCS3.5HC |
57 |
11 |
2.915 (90%) |
2.980 (80%) |
5.25 |
7 |
8.75 |
5 |
1 |
|
M3.5×0.6 |
CPCS3.5HD |
57 |
11 |
2.948 (85%) |
3.013 (75%) |
5.25 |
7 |
8.75 |
5 |
1 |
|
M3.5×0.6 |
CPCS3.5HE |
57 |
11 |
2.980 (80%) |
3.045 (70%) |
5.25 |
7 |
8.75 |
5 |
1 |
|
M3.5×0.6 |
CPCS3.5HF |
57 |
11 |
3.013 (75%) |
3.078 (65%) |
5.25 |
7 |
8.75 |
5 |
1 |
|
M3.5×0.6 |
CPCS3.5HM |
５ piece set consists of CPCS3.5HB ～ CPCS3.5HF（95%〜65%） |
||||||||
|
M3.5×0.6 |
CPCS3.5HS |
５ piece set consists of CPCS3.5HA ～ CPCS3.5HE（100%〜70%） |
||||||||
|
M3.5×0.35 |
CPCS3.5DA |
57 |
11 |
3.121 (100%) |
3.159 (90%) |
5.25 |
7 |
8.75 |
5 |
1 |
|
M3.5×0.35 |
CPCS3.5DB |
57 |
11 |
3.140 (95%) |
3.178 (85%) |
5.25 |
7 |
8.75 |
5 |
1 |
|
M3.5×0.35 |
CPCS3.5DC |
57 |
11 |
3.159 (90%) |
3.197 (80%) |
5.25 |
7 |
8.75 |
5 |
1 |
|
M3.5×0.35 |
CPCS3.5DD |
57 |
11 |
3.178 (85%) |
3.216 (75%) |
5.25 |
7 |
8.75 |
5 |
1 |
|
M3.5×0.35 |
CPCS3.5DE |
57 |
11 |
3.197 (80%) |
3.235 (70%) |
5.25 |
7 |
8.75 |
5 |
1 |
|
M3.5×0.35 |
CPCS3.5DF |
57 |
11 |
3.216 (75%) |
3.254 (65%) |
5.25 |
7 |
8.75 |
5 |
1 |
|
M3.5×0.35 |
CPCS3.5DM |
５ piece set consists of CPCS3.5DB ～ CPCS3.5DF（95%〜65%） |
||||||||
|
M3.5×0.35 |
CPCS3.5DS |
５ piece set consists of CPCS3.5DA ～ CPCS3.5DE（100%〜70%） |
||||||||
|
M4×0.7 |
CPCS4.0IA |
57 |
11 |
3.242 (100%) |
3.318 (90%) |
6 |
8 |
10 |
5 |
1 |
|
M4×0.7 |
CPCS4.0IB |
57 |
11 |
3.280 (95%) |
3.356 (85%) |
6 |
8 |
10 |
5 |
1 |
|
M4×0.7 |
CPCS4.0IC |
57 |
11 |
3.318 (90%) |
3.394 (80%) |
6 |
8 |
10 |
5 |
1 |
|
M4×0.7 |
CPCS4.0ID |
57 |
11 |
3.356 (85%) |
3.432 (75%) |
6 |
8 |
10 |
5 |
1 |
|
M4×0.7 |
CPCS4.0IE |
57 |
11 |
3.394 (80%) |
3.470 (70%) |
6 |
8 |
10 |
5 |
1 |
|
M4×0.7 |
CPCS4.0IF |
57 |
11 |
3.432 (75%) |
3.507 (65%) |
6 |
8 |
10 |
5 |
1 |
|
M4×0.7 |
CPCS4.0IM |
５ piece set consists of CPCS4.0IB ～ CPCS4.0IF（95%〜65%） |
||||||||
|
M4×0.7 |
CPCS4.0IS |
５ piece set consists of CPCS4.0IA ～ CPCS4.0IE（100%〜70%） |
||||||||
|
M4×0.5 |
CPCS4.0GA |
57 |
11 |
3.459 (100%) |
3.513 (90%) |
6 |
8 |
10 |
5 |
1 |
|
M4×0.5 |
CPCS4.0GB |
57 |
11 |
3.486 (95%) |
3.540 (85%) |
6 |
8 |
10 |
5 |
1 |
|
M4×0.5 |
CPCS4.0GC |
57 |
11 |
3.513 (90%) |
3.567 (80%) |
6 |
8 |
10 |
5 |
1 |
|
M4×0.5 |
CPCS4.0GD |
57 |
11 |
3.540 (85%) |
3.594 (75%) |
6 |
8 |
10 |
5 |
1 |
|
M4×0.5 |
CPCS4.0GE |
57 |
11 |
3.567 (80%) |
3.621 (70%) |
6 |
8 |
10 |
5 |
1 |
|
M4×0.5 |
CPCS4.0GF |
57 |
11 |
3.594 (75%) |
3.648 (65%) |
6 |
8 |
10 |
5 |
1 |
|
M4×0.5 |
CPCS4.0GM |
５ piece set consists of CPCS4.0GB ～ CPCS4.0GF（95%〜65%） |
||||||||
|
M4×0.5 |
CPCS4.0GS |
５ piece set consists of CPCS4.0GA ～ CPCS4.0GE（100%〜70%） |
||||||||
|
M4.5×0.75 |
CPCS4.5JA |
65 |
14 |
3.688 (100%) |
3.769 (90%) |
6.75 |
9 |
11.25 |
5.5 |
1 |
|
M4.5×0.75 |
CPCS4.5JB |
65 |
14 |
3.729 (95%) |
3.810 (85%) |
6.75 |
9 |
11.25 |
5.5 |
1 |
|
M4.5×0.75 |
CPCS4.5JC |
65 |
14 |
3.769 (90%) |
3.850 (80%) |
6.75 |
9 |
11.25 |
5.5 |
1 |
|
M4.5×0.75 |
CPCS4.5JD |
65 |
14 |
3.810 (85%) |
3.891 (75%) |
6.75 |
9 |
11.25 |
5.5 |
1 |
|
M4.5×0.75 |
CPCS4.5JE |
65 |
14 |
3.850 (80%) |
3.932 (70%) |
6.75 |
9 |
11.25 |
5.5 |
1 |
|
M4.5×0.75 |
CPCS4.5JF |
65 |
14 |
3.891 (75%) |
3.972 (65%) |
6.75 |
9 |
11.25 |
5.5 |
1 |
|
M4.5×0.75 |
CPCS4.5JM |
５ piece set consists of CPCS4.5JB ～ CPCS4.5JF（95%〜65%） |
||||||||
|
M4.5×0.75 |
CPCS4.5JS |
５ piece set consists of CPCS4.5JA ～ CPCS4.5JE（100%〜70%） |
||||||||
|
M4.5×0.5 |
CPCS4.5GA |
65 |
14 |
3.959 (100%) |
4.013 (90%) |
6.75 |
9 |
11.25 |
5.5 |
1 |
|
M4.5×0.5 |
CPCS4.5GB |
65 |
14 |
3.986 (95%) |
4.040 (85%) |
6.75 |
9 |
11.25 |
5.5 |
1 |
|
M4.5×0.5 |
CPCS4.5GC |
65 |
14 |
4.013 (90%) |
4.067 (80%) |
6.75 |
9 |
11.25 |
5.5 |
1 |
|
M4.5×0.5 |
CPCS4.5GD |
65 |
14 |
4.040 (85%) |
4.094 (75%) |
6.75 |
9 |
11.25 |
5.5 |
1 |
|
M4.5×0.5 |
CPCS4.5GE |
65 |
14 |
4.067 (80%) |
4.121 (70%) |
6.75 |
9 |
11.25 |
5.5 |
1 |
|
M4.5×0.5 |
CPCS4.5GF |
65 |
14 |
4.094 (75%) |
4.148 (65%) |
6.75 |
9 |
11.25 |
5.5 |
1 |
|
M4.5×0.5 |
CPCS4.5GM |
５ piece set consists of CPCS4.5GB ～ CPCS4.5GF（95%〜65%） |
||||||||
|
M4.5×0.5 |
CPCS4.5GS |
５ piece set consists of CPCS4.5GA ～ CPCS4.5GE（100%〜70%） |
||||||||
|
M5×0.8 |
CPCS5.0KA |
65 |
14 |
4.134 (100%) |
4.221 (90%) |
7.5 |
10 |
12.5 |
5.5 |
1 |
|
M5×0.8 |
CPCS5.0KB |
65 |
14 |
4.177 (95%) |
4.264 (85%) |
7.5 |
10 |
12.5 |
5.5 |
1 |
|
M5×0.8 |
CPCS5.0KC |
65 |
14 |
4.221 (90%) |
4.307 (80%) |
7.5 |
10 |
12.5 |
5.5 |
1 |
|
M5×0.8 |
CPCS5.0KD |
65 |
14 |
4.264 (85%) |
4.350 (75%) |
7.5 |
10 |
12.5 |
5.5 |
1 |
|
M5×0.8 |
CPCS5.0KE |
65 |
14 |
4.307 (80%) |
4.394 (70%) |
7.5 |
10 |
12.5 |
5.5 |
1 |
|
M5×0.8 |
CPCS5.0KF |
65 |
14 |
4.350 (75%) |
4.437 (65%) |
7.5 |
10 |
12.5 |
5.5 |
1 |
|
M5×0.8 |
CPCS5.0KM |
５ piece set consists of CPCS5.0KB ～ CPCS5.0KF（95%〜65%） |
||||||||
|
M5×0.8 |
CPCS5.0KS |
５ piece set consists of CPCS5.0KA ～ CPCS5.0KE（100%〜70%） |
||||||||
|
M5×0.5 |
CPCS5.0GA |
65 |
14 |
4.459 (100%) |
4.513 (90%) |
7.5 |
10 |
12.5 |
5.5 |
1 |
|
M5×0.5 |
CPCS5.0GB |
65 |
14 |
4.486 (95%) |
4.540 (85%) |
7.5 |
10 |
12.5 |
5.5 |
1 |
|
M5×0.5 |
CPCS5.0GC |
65 |
14 |
4.513 (90%) |
4.567 (80%) |
7.5 |
10 |
12.5 |
5.5 |
1 |
|
M5×0.5 |
CPCS5.0GD |
65 |
14 |
4.540 (85%) |
4.594 (75%) |
7.5 |
10 |
12.5 |
5.5 |
1 |
|
M5×0.5 |
CPCS5.0GE |
65 |
14 |
4.567 (80%) |
4.621 (70%) |
7.5 |
10 |
12.5 |
5.5 |
1 |
|
M5×0.5 |
CPCS5.0GF |
65 |
14 |
4.594 (75%) |
4.648 (65%) |
7.5 |
10 |
12.5 |
5.5 |
1 |
|
M5×0.5 |
CPCS5.0GM |
５ piece set consists of CPCS5.0GB ～ CPCS5.0GF（95%〜65%） |
||||||||
|
M5×0.5 |
CPCS5.0GS |
５ piece set consists of CPCS5.0GA ～ CPCS5.0GE（100%〜70%） |
||||||||
|
M6×1 |
CPCS6.0MA |
73 |
16.5 |
4.917 (100%) |
5.026 (90%) |
9 |
12 |
15 |
6 |
1 |
|
M6×1 |
CPCS6.0MB |
73 |
16.5 |
4.972 (95%) |
5.080 (85%) |
9 |
12 |
15 |
6 |
1 |
|
M6×1 |
CPCS6.0MC |
73 |
16.5 |
5.026 (90%) |
5.134 (80%) |
9 |
12 |
15 |
6 |
1 |
|
M6×1 |
CPCS6.0MD |
73 |
16.5 |
5.080 (85%) |
5.188 (75%) |
9 |
12 |
15 |
6 |
1 |
|
M6×1 |
CPCS6.0ME |
73 |
16.5 |
5.134 (80%) |
5.242 (70%) |
9 |
12 |
15 |
6 |
1 |
|
M6×1 |
CPCS6.0MF |
73 |
16.5 |
5.188 (75%) |
5.296 (65%) |
9 |
12 |
15 |
6 |
1 |
|
M6×1 |
CPCS6.0MM |
５ piece set consists of CPCS6.0MB ～ CPCS6.0MF（95%〜65%） |
||||||||
|
M6×1 |
CPCS6.0MS |
５ piece set consists of CPCS6.0MA ～ CPCS6.0ME（100%〜70%） |
||||||||
|
M6×0.75 |
CPCS6.0JA |
73 |
16.5 |
5.188 (100%) |
5.269 (90%) |
9 |
12 |
15 |
6 |
1 |
|
M6×0.75 |
CPCS6.0JB |
73 |
16.5 |
5.229 (95%) |
5.310 (85%) |
9 |
12 |
15 |
6 |
1 |
|
M6×0.75 |
CPCS6.0JC |
73 |
16.5 |
5.269 (90%) |
5.350 (80%) |
9 |
12 |
15 |
6 |
1 |
|
M6×0.75 |
CPCS6.0JD |
73 |
16.5 |
5.310 (85%) |
5.391 (75%) |
9 |
12 |
15 |
6 |
1 |
|
M6×0.75 |
CPCS6.0JE |
73 |
16.5 |
5.350 (80%) |
5.432 (70%) |
9 |
12 |
15 |
6 |
1 |
|
M6×0.75 |
CPCS6.0JF |
73 |
16.5 |
5.391 (75%) |
5.472 (65%) |
9 |
12 |
15 |
6 |
1 |
|
M6×0.75 |
CPCS6.0JM |
５ piece set consists of CPCS6.0JB ～ CPCS6.0JF（95%〜65%） |
||||||||
|
M6×0.75 |
CPCS6.0JS |
５ piece set consists of CPCS6.0JA ～ CPCS6.0JE（100%〜70%） |
||||||||
|
M7×1 |
CPCS7.0MA |
99 |
22 |
5.917 (100%) |
6.026 (90%) |
10.5 |
14 |
17.5 |
8 |
1 |
|
M7×1 |
CPCS7.0MB |
99 |
22 |
5.972 (95%) |
6.080 (85%) |
10.5 |
14 |
17.5 |
8 |
1 |
|
M7×1 |
CPCS7.0MC |
99 |
22 |
6.026 (90%) |
6.134 (80%) |
10.5 |
14 |
17.5 |
8 |
1 |
|
M7×1 |
CPCS7.0MD |
99 |
22 |
6.080 (85%) |
6.188 (75%) |
10.5 |
14 |
17.5 |
8 |
1 |
|
M7×1 |
CPCS7.0ME |
99 |
22 |
6.134 (80%) |
6.242 (70%) |
10.5 |
14 |
17.5 |
8 |
1 |
|
M7×1 |
CPCS7.0MF |
99 |
22 |
6.188 (75%) |
6.296 (65%) |
10.5 |
14 |
17.5 |
8 |
1 |
|
M7×1 |
CPCS7.0MM |
５ piece set consists of CPCS7.0MB ～ CPCS7.0MF（95%〜65%） |
||||||||
|
M7×1 |
CPCS7.0MS |
５ piece set consists of CPCS7.0MA ～ CPCS7.0ME（100%〜70%） |
||||||||
|
M7×0.75 |
CPCS7.0JA |
99 |
22 |
6.188 (100%) |
6.269 (90%) |
10.5 |
14 |
17.5 |
8 |
1 |
|
M7×0.75 |
CPCS7.0JB |
99 |
22 |
6.229 (95%) |
6.310 (85%) |
10.5 |
14 |
17.5 |
8 |
1 |
|
M7×0.75 |
CPCS7.0JC |
99 |
22 |
6.269 (90%) |
6.350 (80%) |
10.5 |
14 |
17.5 |
8 |
1 |
|
M7×0.75 |
CPCS7.0JD |
99 |
22 |
6.310 (85%) |
6.391 (75%) |
10.5 |
14 |
17.5 |
8 |
1 |
|
M7×0.75 |
CPCS7.0JE |
99 |
22 |
6.350 (80%) |
6.432 (70%) |
10.5 |
14 |
17.5 |
8 |
1 |
|
M7×0.75 |
CPCS7.0JF |
99 |
22 |
6.391 (75%) |
6.472 (65%) |
10.5 |
14 |
17.5 |
8 |
1 |
|
M7×0.75 |
CPCS7.0JM |
５ piece set consists of CPCS7.0JB ～ CPCS7.0JF（95%〜65%） |
||||||||
|
M7×0.75 |
CPCS7.0JS |
５ piece set consists of CPCS7.0JA ～ CPCS7.0JE（100%〜70%） |
||||||||
|
M8×1.25 |
CPCS8.0NA |
99 |
22 |
6.647 (100%) |
6.782 (90%) |
12 |
16 |
20 |
8 |
1 |
|
M8×1.25 |
CPCS8.0NB |
99 |
22 |
6.714 (95%) |
6.850 (85%) |
12 |
16 |
20 |
8 |
1 |
|
M8×1.25 |
CPCS8.0NC |
99 |
22 |
6.782 (90%) |
6.917 (80%) |
12 |
16 |
20 |
8 |
1 |
|
M8×1.25 |
CPCS8.0ND |
99 |
22 |
6.850 (85%) |
6.985 (75%) |
12 |
16 |
20 |
8 |
1 |
|
M8×1.25 |
CPCS8.0NE |
99 |
22 |
6.917 (80%) |
7.053 (70%) |
12 |
16 |
20 |
8 |
1 |
|
M8×1.25 |
CPCS8.0NF |
99 |
22 |
6.985 (75%) |
7.120 (65%) |
12 |
16 |
20 |
8 |
1 |
|
M8×1.25 |
CPCS8.0NM |
５ piece set consists of CPCS8.0NB ～ CPCS8.0NF（95%〜65%） |
||||||||
|
M8×1.25 |
CPCS8.0NS |
５ piece set consists of CPCS8.0NA ～ CPCS8.0NE（100%〜70%） |
||||||||
|
M8×1 |
CPCS8.0MA |
99 |
22 |
6.917 (100%) |
7.026 (90%) |
12 |
16 |
20 |
8 |
1 |
|
M8×1 |
CPCS8.0MB |
99 |
22 |
6.972 (95%) |
7.080 (85%) |
12 |
16 |
20 |
8 |
1 |
|
M8×1 |
CPCS8.0MC |
99 |
22 |
7.026 (90%) |
7.134 (80%) |
12 |
16 |
20 |
8 |
1 |
|
M8×1 |
CPCS8.0MD |
99 |
22 |
7.080 (85%) |
7.188 (75%) |
12 |
16 |
20 |
8 |
1 |
|
M8×1 |
CPCS8.0ME |
99 |
22 |
7.134 (80%) |
7.242 (70%) |
12 |
16 |
20 |
8 |
1 |
|
M8×1 |
CPCS8.0MF |
99 |
22 |
7.188 (75%) |
7.296 (65%) |
12 |
16 |
20 |
8 |
1 |
|
M8×1 |
CPCS8.0MM |
５ piece set consists of CPCS8.0MB ～ CPCS8.0MF（95%〜65%） |
||||||||
|
M8×1 |
CPCS8.0MS |
５ piece set consists of CPCS8.0MA ～ CPCS8.0ME（100%〜70%） |
||||||||
|
M8×0.75 |
CPCS8.0JA |
99 |
22 |
7.188 (100%) |
7.269 (90%) |
12 |
16 |
20 |
8 |
1 |
|
M8×0.75 |
CPCS8.0JB |
99 |
22 |
7.229 (95%) |
7.310 (85%) |
12 |
16 |
20 |
8 |
1 |
|
M8×0.75 |
CPCS8.0JC |
99 |
22 |
7.269 (90%) |
7.350 (80%) |
12 |
16 |
20 |
8 |
1 |
|
M8×0.75 |
CPCS8.0JD |
99 |
22 |
7.310 (85%) |
7.391 (75%) |
12 |
16 |
20 |
8 |
1 |
|
M8×0.75 |
CPCS8.0JE |
99 |
22 |
7.350 (80%) |
7.432 (70%) |
12 |
16 |
20 |
8 |
1 |
|
M8×0.75 |
CPCS8.0JF |
99 |
22 |
7.391 (75%) |
7.472 (65%) |
12 |
16 |
20 |
8 |
1 |
|
M8×0.75 |
CPCS8.0JM |
５ piece set consists of CPCS8.0JB ～ CPCS8.0JF（95%〜65%） |
||||||||
|
M8×0.75 |
CPCS8.0JS |
５ piece set consists of CPCS8.0JA ～ CPCS8.0JE（100%〜70%） |
||||||||
|
M9×1.25 |
CPCS9.0NA |
110 |
27.5 |
7.647 (100%) |
7.782 (90%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×1.25 |
CPCS9.0NB |
110 |
27.5 |
7.714 (95%) |
7.850 (85%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×1.25 |
CPCS9.0NC |
110 |
27.5 |
7.782 (90%) |
7.917 (80%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×1.25 |
CPCS9.0ND |
110 |
27.5 |
7.850 (85%) |
7.985 (75%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×1.25 |
CPCS9.0NE |
110 |
27.5 |
7.917 (80%) |
8.053 (70%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×1.25 |
CPCS9.0NF |
110 |
27.5 |
7.985 (75%) |
8.120 (65%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×1.25 |
CPCS9.0NM |
５ piece set consists of CPCS9.0NB ～ CPCS9.0NF（95%〜65%） |
||||||||
|
M9×1.25 |
CPCS9.0NS |
５ piece set consists of CPCS9.0NA ～ CPCS9.0NE（100%〜70%） |
||||||||
|
M9×1 |
CPCS9.0MA |
110 |
27.5 |
7.917 (100%) |
8.026 (90%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×1 |
CPCS9.0MB |
110 |
27.5 |
7.972 (95%) |
8.080 (85%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×1 |
CPCS9.0MC |
110 |
27.5 |
8.026 (90%) |
8.134 (80%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×1 |
CPCS9.0MD |
110 |
27.5 |
8.080 (85%) |
8.188 (75%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×1 |
CPCS9.0ME |
110 |
27.5 |
8.134 (80%) |
8.242 (70%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×1 |
CPCS9.0MF |
110 |
27.5 |
8.188 (75%) |
8.296 (65%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×1 |
CPCS9.0MM |
５ piece set consists of CPCS9.0MB ～ CPCS9.0MF（95%〜65%） |
||||||||
|
M9×1 |
CPCS9.0MS |
５ piece set consists of CPCS9.0MA ～ CPCS9.0ME（100%〜70%） |
||||||||
|
M9×0.75 |
CPCS9.0JA |
110 |
27.5 |
8.188 (100%) |
8.269 (90%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×0.75 |
CPCS9.0JB |
110 |
27.5 |
8.229 (95%) |
8.310 (85%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×0.75 |
CPCS9.0JC |
110 |
27.5 |
8.269 (90%) |
8.350 (80%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×0.75 |
CPCS9.0JD |
110 |
27.5 |
8.310 (85%) |
8.391 (75%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×0.75 |
CPCS9.0JE |
110 |
27.5 |
8.350 (80%) |
8.432 (70%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×0.75 |
CPCS9.0JF |
110 |
27.5 |
8.391 (75%) |
8.472 (65%) |
13.5 |
18 |
22.5 |
10 |
1 |
|
M9×0.75 |
CPCS9.0JM |
５ piece set consists of CPCS9.0JB ～ CPCS9.0JF（95%〜65%） |
||||||||
|
M9×0.75 |
CPCS9.0JS |
５ piece set consists of CPCS9.0JA ～ CPCS9.0JE（100%〜70%） |
||||||||
|
M10×1.5 |
CPCS010OA |
110 |
27.5 |
8.376 (100%) |
8.538 (90%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1.5 |
CPCS010OB |
110 |
27.5 |
8.457 (95%) |
8.620 (85%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1.5 |
CPCS010OC |
110 |
27.5 |
8.538 (90%) |
8.701 (80%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1.5 |
CPCS010OD |
110 |
27.5 |
8.620 (85%) |
8.782 (75%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1.5 |
CPCS010OE |
110 |
27.5 |
8.701 (80%) |
8.863 (70%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1.5 |
CPCS010OF |
110 |
27.5 |
8.782 (75%) |
8.944 (65%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1.5 |
CPCS010OM |
５ piece set consists of CPCS010OB ～ CPCS010OF（95%〜65%） |
||||||||
|
M10×1.5 |
CPCS010OS |
５ piece set consists of CPCS010OA ～ CPCS010OE（100%〜70%） |
||||||||
|
M10×1.25 |
CPCS010NA |
110 |
27.5 |
8.647 (100%) |
8.782 (90%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1.25 |
CPCS010NB |
110 |
27.5 |
8.714 (95%) |
8.850 (85%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1.25 |
CPCS010NC |
110 |
27.5 |
8.782 (90%) |
8.917 (80%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1.25 |
CPCS010ND |
110 |
27.5 |
8.850 (85%) |
8.985 (75%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1.25 |
CPCS010NE |
110 |
27.5 |
8.917 (80%) |
9.053 (70%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1.25 |
CPCS010NF |
110 |
27.5 |
8.985 (75%) |
9.120 (65%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1.25 |
CPCS010NM |
５ piece set consists of CPCS010NB ～ CPCS010NF（95%〜65%） |
||||||||
|
M10×1.25 |
CPCS010NS |
５ piece set consists of CPCS010NA ～ CPCS010NE（100%〜70%） |
||||||||
|
M10×1 |
CPCS010MA |
110 |
27.5 |
8.917 (100%) |
9.026 (90%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1 |
CPCS010MB |
110 |
27.5 |
8.972 (95%) |
9.080 (85%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1 |
CPCS010MC |
110 |
27.5 |
9.026 (90%) |
9.134 (80%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1 |
CPCS010MD |
110 |
27.5 |
9.080 (85%) |
9.188 (75%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1 |
CPCS010ME |
110 |
27.5 |
9.134 (80%) |
9.242 (70%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1 |
CPCS010MF |
110 |
27.5 |
9.188 (75%) |
9.296 (65%) |
15 |
20 |
25 |
10 |
1 |
|
M10×1 |
CPCS010MM |
５ piece set consists of CPCS010MB ～ CPCS010MF（95%〜65%） |
||||||||
|
M10×1 |
CPCS010MS |
５ piece set consists of CPCS010MA ～ CPCS010ME（100%〜70%） |
||||||||
|
M10×0.75 |
CPCS010JA |
110 |
27.5 |
9.188 (100%) |
9.269 (90%) |
15 |
20 |
25 |
10 |
1 |
|
M10×0.75 |
CPCS010JB |
110 |
27.5 |
9.229 (95%) |
9.310 (85%) |
15 |
20 |
25 |
10 |
1 |
|
M10×0.75 |
CPCS010JC |
110 |
27.5 |
9.269 (90%) |
9.350 (80%) |
15 |
20 |
25 |
10 |
1 |
|
M10×0.75 |
CPCS010JD |
110 |
27.5 |
9.310 (85%) |
9.391 (75%) |
15 |
20 |
25 |
10 |
1 |
|
M10×0.75 |
CPCS010JE |
110 |
27.5 |
9.350 (80%) |
9.432 (70%) |
15 |
20 |
25 |
10 |
1 |
|
M10×0.75 |
CPCS010JF |
110 |
27.5 |
9.391 (75%) |
9.472 (65%) |
15 |
20 |
25 |
10 |
1 |
|
M10×0.75 |
CPCS010JM |
５ piece set consists of CPCS010JB ～ CPCS010JF（95%〜65%） |
||||||||
|
M10×0.75 |
CPCS010JS |
５ piece set consists of CPCS010JA ～ CPCS010JE（100%〜70%） |
||||||||
|
M11×1.5 |
CPCS011OA |
121 |
33 |
9.376 (100%) |
9.538 (90%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×1.5 |
CPCS011OB |
121 |
33 |
9.457 (95%) |
9.620 (85%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×1.5 |
CPCS011OC |
121 |
33 |
9.538 (90%) |
9.701 (80%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×1.5 |
CPCS011OD |
121 |
33 |
9.620 (85%) |
9.782 (75%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×1.5 |
CPCS011OE |
121 |
33 |
9.701 (80%) |
9.863 (70%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×1.5 |
CPCS011OF |
121 |
33 |
9.782 (75%) |
9.944 (65%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×1.5 |
CPCS011OM |
５ piece set consists of CPCS011OB ～ CPCS011OF（95%〜65%） |
||||||||
|
M11×1.5 |
CPCS011OS |
５ piece set consists of CPCS011OA ～ CPCS011OE（100%〜70%） |
||||||||
|
M11×1 |
CPCS011MA |
121 |
33 |
9.917 (100%) |
10.026 (90%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×1 |
CPCS011MB |
121 |
33 |
9.972 (95%) |
10.080 (85%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×1 |
CPCS011MC |
121 |
33 |
10.026 (90%) |
10.134 (80%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×1 |
CPCS011MD |
121 |
33 |
10.080 (85%) |
10.188 (75%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×1 |
CPCS011ME |
121 |
33 |
10.134 (80%) |
10.242 (70%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×1 |
CPCS011MF |
121 |
33 |
10.188 (75%) |
10.296 (65%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×1 |
CPCS011MM |
５ piece set consists of CPCS011MB ～ CPCS011MF（95%〜65%） |
||||||||
|
M11×1 |
CPCS011MS |
５ piece set consists of CPCS011MA ～ CPCS011ME（100%〜70%） |
||||||||
|
M11×0.75 |
CPCS011JA |
121 |
33 |
10.188 (100%) |
10.269 (90%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×0.75 |
CPCS011JB |
121 |
33 |
10.229 (95%) |
10.310 (85%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×0.75 |
CPCS011JC |
121 |
33 |
10.269 (90%) |
10.350 (80%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×0.75 |
CPCS011JD |
121 |
33 |
10.310 (85%) |
10.391 (75%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×0.75 |
CPCS011JE |
121 |
33 |
10.350 (80%) |
10.432 (70%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×0.75 |
CPCS011JF |
121 |
33 |
10.391 (75%) |
10.472 (65%) |
16.5 |
22 |
27.5 |
12 |
1 |
|
M11×0.75 |
CPCS011JM |
５ piece set consists of CPCS011JB ～ CPCS011JF（95%〜65%） |
||||||||
|
M11×0.75 |
CPCS011JS |
５ piece set consists of CPCS011JA ～ CPCS011JE（100%〜70%） |
||||||||
|
M12×1.75 |
CPCS012PA |
121 |
33 |
10.105 (100%) |
10.295 (90%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.75 |
CPCS012PB |
121 |
33 |
10.200 (95%) |
10.390 (85%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.75 |
CPCS012PC |
121 |
33 |
10.295 (90%) |
10.484 (80%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.75 |
CPCS012PD |
121 |
33 |
10.390 (85%) |
10.579 (75%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.75 |
CPCS012PE |
121 |
33 |
10.484 (80%) |
10.674 (70%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.75 |
CPCS012PF |
121 |
33 |
10.579 (75%) |
10.769 (65%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.75 |
CPCS012PM |
５ piece set consists of CPCS012PB ～ CPCS012PF（95%〜65%） |
||||||||
|
M12×1.75 |
CPCS012PS |
５ piece set consists of CPCS012PA ～ CPCS012PE（100%〜70%） |
||||||||
|
M12×1.5 |
CPCS012OA |
121 |
33 |
10.376 (100%) |
10.538 (90%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.5 |
CPCS012OB |
121 |
33 |
10.457 (95%) |
10.620 (85%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.5 |
CPCS012OC |
121 |
33 |
10.538 (90%) |
10.701 (80%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.5 |
CPCS012OD |
121 |
33 |
10.620 (85%) |
10.782 (75%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.5 |
CPCS012OE |
121 |
33 |
10.701 (80%) |
10.863 (70%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.5 |
CPCS012OF |
121 |
33 |
10.782 (75%) |
10.944 (65%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.5 |
CPCS012OM |
５ piece set consists of CPCS012OB ～ CPCS012OF（95%〜65%） |
||||||||
|
M12×1.5 |
CPCS012OS |
５ piece set consists of CPCS012OA ～ CPCS012OE（100%〜70%） |
||||||||
|
M12×1.25 |
CPCS012NA |
121 |
33 |
10.647 (100%) |
10.782 (90%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.25 |
CPCS012NB |
121 |
33 |
10.714 (95%) |
10.850 (85%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.25 |
CPCS012NC |
121 |
33 |
10.782 (90%) |
10.917 (80%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.25 |
CPCS012ND |
121 |
33 |
10.850 (85%) |
10.985 (75%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.25 |
CPCS012NE |
121 |
33 |
10.917 (80%) |
11.053 (70%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.25 |
CPCS012NF |
121 |
33 |
10.985 (75%) |
11.120 (65%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1.25 |
CPCS012NM |
５ piece set consists of CPCS012NB ～ CPCS012NF（95%〜65%） |
||||||||
|
M12×1.25 |
CPCS012NS |
５ piece set consists of CPCS012NA ～ CPCS012NE（100%〜70%） |
||||||||
|
M12×1 |
CPCS012MA |
121 |
33 |
10.917 (100%) |
11.026 (90%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1 |
CPCS012MB |
121 |
33 |
10.972 (95%) |
11.080 (85%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1 |
CPCS012MC |
121 |
33 |
11.026 (90%) |
11.134 (80%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1 |
CPCS012MD |
121 |
33 |
11.080 (85%) |
11.188 (75%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1 |
CPCS012ME |
121 |
33 |
11.134 (80%) |
11.242 (70%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1 |
CPCS012MF |
121 |
33 |
11.188 (75%) |
11.296 (65%) |
18 |
24 |
30 |
12 |
1 |
|
M12×1 |
CPCS012MM |
５ piece set consists of CPCS012MB ～ CPCS012MF（95%〜65%） |
||||||||
|
M12×1 |
CPCS012MS |
５ piece set consists of CPCS012MA ～ CPCS012ME（100%〜70%） |
||||||||
| แบรนด์สินค้า | YAMAWA |
|---|
เขียนรีวิวสินค้าของคุณเอง
