CPR-T (Metric Threads) | Check Pins for Bored Holes in Thread Form Tapping (Taper Type) | YAMAWA
ราคาต่ำสุด
THB 0.00
ราคาปรกติ
THB 233.64
พร้อมส่ง
SKU
CPR-T (Metric Threads)
- One CPR-T enables simple checking of bored hole dia. (for thread forming taps, taper type). CPR-T is made from wear resistant HSS material is applicable for through hole and for blind hole having enough space in the bottom.
Specification
Segment：7C
|
Size |
Code |
L (mm) |
ℓ (mm) |
d1 (mm) |
d2 (mm) |
ℓ1 (mm) |
ℓ2 (mm) |
Ds (mm) |
K (mm) |
ℓk (mm) |
TYPE |
|
For Metric Threads |
|||||||||||
|
M2×0.4 |
CPRT2.0E |
42 |
7 |
1.79 |
1.84 |
1 |
6 |
3 |
2.5 |
5 |
1 |
|
M2×0.25 |
CPRT2.0B |
42 |
7 |
1.89 |
1.92 |
1 |
6 |
3 |
2.5 |
5 |
1 |
|
M2.5×0.45 |
CPRT2.5F |
46 |
8 |
2.27 |
2.34 |
1.5 |
6.5 |
3 |
2.5 |
5 |
1 |
|
M2.5×0.35 |
CPRT2.5D |
46 |
8 |
2.34 |
2.38 |
1.5 |
6.5 |
3 |
2.5 |
5 |
1 |
|
M2.6×0.45 |
CPRT2.6F |
46 |
8 |
2.37 |
2.44 |
1.5 |
6.5 |
3 |
2.5 |
5 |
1 |
|
M3×0.5 |
CPRT3.0G |
46 |
8.5 |
2.75 |
2.82 |
1.5 |
7 |
4 |
3.2 |
6 |
1 |
|
M3×0.35 |
CPRT3.0D |
46 |
8.5 |
2.84 |
2.88 |
1.5 |
7 |
4 |
3.2 |
6 |
1 |
|
M3.5×0.6 |
CPRT3.5H |
52 |
10.5 |
3.19 |
3.27 |
2.25 |
8.25 |
5 |
4 |
7 |
1 |
|
M3.5×0.35 |
CPRT3.5D |
52 |
10.5 |
3.34 |
3.38 |
2.25 |
8.25 |
5 |
4 |
7 |
1 |
|
M4×0.7 |
CPRT4.0I |
52 |
10.5 |
3.65 |
3.72 |
2.25 |
8.25 |
5 |
4 |
7 |
1 |
|
M4×0.5 |
CPRT4.0G |
52 |
10.5 |
3.76 |
3.83 |
2.25 |
8.25 |
5 |
4 |
7 |
1 |
|
M5×0.8 |
CPRT5.0K |
59.5 |
12.5 |
4.59 |
4.67 |
2.5 |
10 |
5.5 |
4.5 |
7 |
1 |
|
M5×0.5 |
CPRT5.0G |
59.5 |
12.5 |
4.76 |
4.83 |
2.5 |
10 |
5.5 |
4.5 |
7 |
1 |
|
M6×1 |
CPRT6.0M |
61.5 |
16.5 |
5.49 |
5.59 |
3.75 |
12.75 |
6 |
4.5 |
7 |
1 |
|
M6×0.75 |
CPRT6.0J |
61.5 |
16.5 |
5.61 |
5.69 |
3.75 |
12.75 |
6 |
4.5 |
7 |
1 |
|
M7×1 |
CPRT7.0M |
90 |
19.4 |
6.49 |
6.59 |
4.7 |
14.7 |
8 |
6.2 |
9 |
2 |
|
M7×0.75 |
CPRT7.0J |
90 |
19.4 |
6.62 |
6.70 |
4.7 |
14.7 |
8 |
6.2 |
9 |
2 |
|
M8×1.25 |
CPRT8.0N |
90 |
19.4 |
7.36 |
7.49 |
4.7 |
14.7 |
8 |
6.2 |
9 |
2 |
|
M8×1 |
CPRT8.0M |
90 |
19.4 |
7.49 |
7.59 |
4.7 |
14.7 |
8 |
6.2 |
9 |
2 |
|
M8×0.75 |
CPRT8.0J |
90 |
19.4 |
7.62 |
7.70 |
4.7 |
14.7 |
8 |
6.2 |
9 |
2 |
|
M10×1.5 |
CPRT010O |
100 |
23.4 |
9.22 |
9.34 |
6.7 |
16.7 |
10 |
8 |
11 |
2 |
|
M10×1.25 |
CPRT010N |
100 |
23.4 |
9.35 |
9.49 |
6.7 |
16.7 |
10 |
8 |
11 |
2 |
|
M10×1 |
CPRT010M |
100 |
23.4 |
9.49 |
9.59 |
6.7 |
16.7 |
10 |
8 |
11 |
2 |
|
M12×1.75 |
CPRT012P |
110 |
27.4 |
11.09 |
11.23 |
7.7 |
19.7 |
12 |
9 |
12 |
2 |
|
M12×1.5 |
CPRT012O |
110 |
27.4 |
11.22 |
11.34 |
7.7 |
19.7 |
12 |
9 |
12 |
2 |
|
M12×1.25 |
CPRT012N |
110 |
27.4 |
11.36 |
11.50 |
7.7 |
19.7 |
12 |
9 |
12 |
2 |
|
M12×1 |
CPRT012M |
110 |
27.4 |
11.49 |
11.59 |
7.7 |
19.7 |
12 |
9 |
12 |
2 |
| แบรนด์สินค้า | YAMAWA |
|---|
