CSP | Interchangeable Head Type Preset Torque Wrench | TOHNICHI
ราคาต่ำสุด
THB 0.00
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
CSP
QTY:
0
Interchangeable head version of QSP
No external scale, torque set by a torque wrench tester
| Head Size | Model | Torque Range | Overall Length [mm] | Weight [kg | ||
| [N•m] | [kgf•cm] | [lbf•in] | ||||
| Min.-Max. | Min.-Max. | Min.-Max. | ||||
| 6D | CSP2N×6D | 0.4-2 | 4-20 | 3.5-17.7 | 133 | 0.06 |
| CSP5N×6D | 1-5 | 10-50 | 8.8-44.2 | |||
| 8D | CSP1.5N4×8D | 0.3-1.5 | 3-15 | 2.7-13.2 | 130 | 0.2 |
| CSP3N4×8D | 0.6-3 | 6-30 | 5.3-26.5 | |||
| CSP6N4×8D | 1-6 | 10-60 | 8.9-53.0 | 165 | ||
| CSP12N4×8D | 2-12 | 20-120 | 17.7-106 | |||
| 10D | CSP25N3×10D | 5-25 | 50-250 | 45-221 | 195 | |
| 12D | CSP50N3×12D | 10-50 | 100-500 | 89-442 | 215 | 0.3 |
| 15D | CSP50N3×15D | 220 | ||||
| CSP100N3×15D | 20-100 | 200-1000 | 177-885 | 290 | 0.45 | |
| CSP140N3×15D | 30-140 | 300-1400 | 266-1238 | 350 | 0.55 | |
| 19D | CSP200N3×19D | 40-200 | 400-2000 | 354-1769 | 430 | 1.0 |
| 20D | CSP280N3×22D | 40-280 | 4-28 | 354-2477 | 625 | 1.4 |
| CSP420N3×22D | 60-420 | 642 | 531-3716 | 920 | 2.7 | |
| แบรนด์สินค้า | TOHNICHI |
|---|
