Dial Upright Gauges
R Series
Best suited for measuring precision parts and testing materials like rubber, leather, fabric and plastic etc.
Rubber, leather, urethane and film can be easily measured by this system.
● The table of R1 series are adjustable up and down by the nut installed side way.
● The dial gauge is affixed to the body.
Specifications
| Order No. | Dial Indicator (standard attachments) | Indication error (μm) |
Table diameter (mm) |
Contact point dia. (mm) |
Measuring force less than (N) |
Measuring depth (mm) |
Effective measuring range(mm) |
Total height (mm) |
||
| Gauge installed | Range (mm) | Graduation (mm) | ||||||||
| R1-A | 25F-RE | 2 | 0.001 | ±7 | 40 | 5 | 1.5 | 55 | 10 | 191 |
| R1-B | 107F-RE | 10 | 0.01 | ±15 | 40 | 5 | 1.4 | 55 | 25 | 190 |
| R1-C | 207F-PL | 20 | 0.01 | ±22 | 40 | 5 | 2.0 | 55 | 20 | 210 |
| แบรนด์สินค้า | PEACOCK |
|---|
