Digimatic Holtest SERIES 468 — Three-point Bore Micrometers - Non-interchangeable Head Sets | MITUTOYO
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 75,926.00
พร้อมส่ง
SKU
HTD-RFST-SET
• These three-point bore Digimatic micrometers for inside measurement are suitable for highly accurate measurements.
• Can measure deep holes using an extension rod (optional).
• Can measure close to the bottom of a blind hole.
• Titanium-coated measuring pins provide excellent durability and impact resistance.
• Two values can be preset as a reference point, allowing you to store multiple measured values of setting rings and to quickly prepare for measurement.
SPECIFICATIONS
Metric
| Order No. | Range*² (mm) |
Content of set | Extension rod (optional) |
| 468-981 | 6 - 12 | Display unit 6 - 8 mm 1 pc. 8 - 10 mm 1 pc. 10 - 12 mm 1 pc. Setting ring (ø8, ø10) 1 pc. each Spanner 2 pcs. Hex wrench 1 pc. Phillips screwdriver 1 pc. |
100 mm 1 pc. |
| 468-982 | 12 - 25 | Display unit 12 - 16 mm 1 pc. 16 - 20 mm 1 pc. 20 - 25 mm 1 pc. Setting ring (ø16, ø20) 1 pc. each Spanner 2 pcs. Hex wrench 1 pc. Phillips screwdriver 1 pc. |
150 mm 2 pcs.*¹ |
| 468-983 | 25 - 50 | Display unit 25 - 30 mm 1 pc. 30 - 40 mm 1 pc. 40 - 50 mm 1 pc. Setting ring (ø30, ø40) 1 pc. each Spanner 1 pcs. Hex wrench 1 pc. Phillips screwdriver 1 pc. |
150 mm 1 pc. |
| 468-984 | 50 - 75 | Display unit 50 - 63 mm 1 pc. 62 - 75 mm 1 pc. Setting ring ((ø62) 1 pc. each Spanner 1 pcs. Hex wrench 1 pc. Phillips screwdriver 1 pc. |
150 mm 1 pc. |
| 468-985 | 75 - 100 | Display unit 75 - 88 mm 1 pc. 87 - 100 mm 1 pc. Setting ring ((ø87) 1 pc. each Spanner 1 pcs. Hex wrench 1 pc. Phillips screwdriver 1 pc. |
150 mm 1 pc. |
Inch / Metric
| Order No. | Range* (in) |
Content of set | Extension rod (optional) |
| 468-986 | 0.275 - 0.5 | Display unit 0.275 - 0.35 in 1 pc. 0.35 - 0.425 in 1 pc. 0.425 - 0.5 in 1 pc. Setting ring 1 pc. each (0.35 in DIA., 0.425 in DIA.) Spanner 2 pcs. Hex wrench 1 pc. Phillips screwdriver 1 pc. |
100 mm 1 pc. |
| 468-987 | 0.5 - 1 | Display unit 0.5 - 0.65 in 1 pc. 0.65 - 0.8 in 1 pc. 0.8 - 1 in 1 pc. Setting ring 1 pc. each (0.65 in DIA., 0.8 in DIA.) Spanner 2 pcs. Hex wrench 1 pc. Phillips screwdriver 1 pc. |
150 mm 2 pcs.*¹ |
| 468-988 | 1 - 2 | Display unit 1 - 1.2 in 1 pc. 1.2 - 1.6 in 1 pc. 1.6 - 2 in 1 pc. Setting ring 1 pc. each (1.2 in DIA., 1.6 in DIA.) Spanner 1 pcs. Hex wrench 1 pc. Phillips screwdriver 1 pc. |
150 mm 1 pc. |
| 468-989 | 2 - 3 | Display unit 2 - 2.5 in 1 pc. 2.5 - 3 in 1 pc.. Setting ring 1 pc. each (2.5 in DIA.) Spanner 1 pcs. Hex wrench 1 pc. Phillips screwdriver 1 pc. |
150 mm 1 pc. |
| 468-990 | 3 - 4 | Display unit 3 - 3.5 in 1 pc. 3.5 - 4 in 1 pc. Setting ring 1 pc. each (3.5 in DIA.) Spanner 1 pcs. Hex wrench 1 pc. Phillips screwdriver 1 pc. |
150 mm 1 pc. |
*1 Total 2 pcs. of extension rods: Code No. 952621 (for measuring range 12 to 16 mm, 16 to 20 mm) and code No. 952622 (for measuring range 20 to 25 mm).
Two extension rods cannot be connected due to the different mounting positions.
*2 The measurement range cannot be enlarged by measuring heads that are not standard-supplied (the accuracy is not guaranteed).
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Digital/Analog | Digital |
