Digimatic Micrometer Heads SERIES 350 - IP65 | MITUTOYO
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 7,007.43
พร้อมส่ง
SKU
1MIT-350-IP65
• Easy-to-read digital display.
• All models support data output.
SPECIFICATIONS
Metric
| Order No. | Range (mm) |
Resolution (mm) |
Graduation (mm) |
Stem | Stem dia. (mm) |
Spindle end | Graduation features |
Maximum permissible error J MPE (μm) |
| 164-163 | 0 - 50 | 0.001 | — | Plain | 18 | Flat (carbide tip) | — | ±3 |
| 350-251-30* | 0 - 25 | 0.01 | 10 | Standard | ±2 | |||
| 350-252-30* | W/clamp nut | |||||||
| 350-253-30* | Plain | Spherical (SR4) (carbide tip) |
||||||
| 350-254-30* | W/clamp nut | |||||||
| 350-281-30** | Plain | 12 | Flat (carbide tip) | |||||
| 350-282-30** | W/clamp nut | |||||||
| 350-283-30** | Plain | Spherical (SR4) (carbide tip) |
||||||
| 350-284-30** | W/clamp nut | |||||||
| 350-261-30** | Plain | Flat | ||||||
| 350-271-30** | ||||||||
| 350-272-30* | W/clamp nut | |||||||
| 350-273-30** | Plain | Spherical (SR4) (carbide tip) |
||||||
| 350-274-30* | W/clamp nut |
Inch/Metric
| Order No. | Range (in) |
Resolution | Graduation | Stem | Stem dia. (in) |
Spindle end | Graduation features |
Maximum permissible error J MPE (in) |
| 164-164 | 0 - 2 | 0.00005 in/ 0.001 mm |
— | Plain | 0.709 |
Flat (carbide tip) |
— | ±0.00015 |
| 350-351-30* | 0 - 1 | 0.001 in/ 0.01 mm |
0.375 | Standard | ±0.0001 | |||
| 350-352-30* | W/clamp nut | |||||||
| 350-353-30* | Plain | Spherical (SR4) (carbide tip) |
||||||
| 350-354-30* | W/clamp nut | |||||||
| 350-357-30* | Plain | |||||||
| 350-381-30** | 0.5 | Flat (carbide tip) | ||||||
| 350-382-30** | W/clamp nut | |||||||
| 350-383-30** | Plain | Spherical (SR4) (carbide tip) |
||||||
| 350-384-30** | W/clamp nut | |||||||
| 350-361-30** | Plain | Flat |
Power source for series 350: SR44 battery (1 pc.), 938882 included as standard (for operational checks)
Power source for series 164: SR44 battery (2 pcs.), 938882 included as standard (for operational checks)
• Battery life:
Approx. 2.4 years under normal use (for 350-XXX)
Approx. 1.8 years under normal use (for 164-163, 164)
• Measuring face: Material / Carbide tip, Hardness / 90 HRA or more, Lapped
• Scale finishing: Satin-chrome plated
* These models are not water-proof.
** IP65 dust / water protection type. Stem diameter of IP65 type is 12 mm.
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Digital/Analog | Digital |
