Digital Indicator PC Series (0.01/ 0.0005mm) - Measuring Range 25.4mm Type / Standard Model | TECLOCK
ราคาต่ำสุด
THB 0.00
พร้อมส่ง
SKU
TEC-PC-25.4
Digital Indicator PC Series (0.01/ 0.0005mm)
Measuring Range 25.4mm Type / Standard Model
• Data output and statistics transaction can be easily made by using digital indicator.
• 0.01mm and 0.0005mm resolution digital indicators are available.
• Standard models are equipped with preset function and conventional models deleting preset functions are available.
Specifications
| Order No. | PC-450A-f | PC-455A-f |
| Measuring range | 25.4mm | |
| Resolution | 0.01mm | 0.0005/0.001/0.01mm |
| Error of indication for the total measuring range (MPEE) | 20μm | 3μm |
| Hysteresis(MPEH) | 20μm | 2μm |
| Repeatability(MPER) | 10μm | 2μm |
| Measuring force(MPL) | 1.8N or less | 1.8N or less |
| Functions | Zero set, Preset, Peak detection, Counting direction switching, Tolerance judgment, Simple calculation, Key customize, Function lock, Auto OFF, Calibration schedule, warning display, Display rotate(330°),Battery voltage decrease display, Error warning display, Data output(DIGIMATIC) |
|
| Display of analog bar | ±20 scale | |
| Power supply | Lithium metal battery CR2032 | |
| Battery life | Normal use: Approx. 2.5 years |
|
| Temperature range | Operation: 0 °C –40 °C, Storage: -10 °C –60 °C | |
| Contact point | Shape : R1.5mm(carbide), thread : M2.5 × 0.45mm | |
| Backs | Flat | |
| Mass | 190g | 195g |
| แบรนด์สินค้า | TECLOCK |
|---|
