DM-250 | Dial Depth Gauge : Measuring Range 5 mm | TECLOCK
THB 0.00
พร้อมส่ง
SKU
DM-250
Dial Depth Gauge - Measuring Range: 5mm
·Small type
• Dial Depth Gauge can be used to measure depth and steps of work piece and coating thickness.
• 5-240mm range (with the supplied extension rods) are available for wide application.
• Special order is applicable for contact point and base.
• Low measuring force type is also available, which seldom hurts work piece.
• Lifting lever (Option) can be mounted.
Specifications
| Order No. | Graduation (mm) |
Measuring Range (mm) |
Indication Error (μm) |
Contact Point Form (mm) |
Standard Contact Point | Measuring Force (N) | Weight (g) |
Old Model |
| DM-250 | 0.01 | 5 | ±10 | Needle | ZS-518 | 1.4 or less | 230 | DM-205 |
| แบรนด์สินค้า | TECLOCK |
|---|---|
| Order No. | DM-250 |
| Graduation | 0.01 mm |
| Measuring Range | 5 mm |
| Indication Error | ±10 μm |
| Contact Point Form | Needle |
| Standard Contact Point | ZS-518 |
| Measuring force (N) | 1.4 or less |
