DM-283 | Dial Depth Gauge (Special) : Round Base type | TECLOCK
THB 0.00
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
DM-283
QTY:
2
Dial Depth Gauge (Special) - Round Base type
·Base form φ25mm
Specifications
| Order No. | Graduation (mm) |
Measuring Range (mm) |
Indication Error (μm) |
Contact Point Form (mm) |
Standard Contact Point | Measuring Force (N) | Weight (g) |
| DM-280 | 0.01 | 10 | ±12 | Needle | ZS-523 | 1.4 or less | 175 |
| DM-283 | 0.01 | 10 | ±12 | φ3.2 Steel Ball | ZS-034 | 1.4 or less | 185 |
| แบรนด์สินค้า | TECLOCK |
|---|---|
| Order No. | DM-283 |
| Graduation | 0.01 mm |
| Measuring Range | 10 mm |
| Indication Error | ±12 μm |
| Contact Point Form | φ3.2 Steel Ball |
| Standard Contact Point | ZS-523 |
| Measuring force (N) | 1.4 or less |
