DTP-50M (013207) | TOOL POINT GAUGE WITH DIAL GAUGE| SK NIIGATASEIKI
THB 0.00
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
013207
QTY:
10
Position detection with dial gauge for
O-standard of Z-axis
USE
● Position detection with dial gauge
MATERIAL
●Measuring surface: SKD11
● Body： Carbon steel for machine structural use
FEATURES
● Preset gauge with dial indicator
● Easy zero setting with dial gauge
● With magnet at the bottom surface
| Order No. | Model No. | Nominal Size (mm) |
Accuracy (mm) |
Repeatability (m) |
Measuring Force less than |
Dial gauge Graduation （mm） |
| 013207 | DTP-50M | 50 | 50 +0.005 0 |
± 10μm | less than 5N | 0.01 |
| Stroke | Magnetic Force | Weight |
| 2mm | 100N | 840g |
| แบรนด์สินค้า | NIIGATA SEIKI (SK) |
|---|
