Extension Rod SERIES 511 — Accessories for Bore Gages | MITUTOYO
ราคาต่ำสุด
THB 0.00
THB 0.00
พร้อมส่ง
SKU
EXTENSION-ROD
• Extension rods are available to assist in deep-hole measurement. (For applicable combination with bore gages, see the table below)
Note 1: When using a 500 mm (or longer) extension rod, use the bore gage in an upright position.
Note 2: Only one extension rod can be attached to a bore gage. It is not possible to use more than one extension rod.
Note 3: The extension rod cannot be used for products with a custom size or custom specifications.
| Applicable model | Extension rod length (mm) | Extension rod diameter (mm) |
Spanner code No. | ||||
| Code No. | 125 | 250 | 500 | 750 | 1000 | ||
| 511-701/511-731 | 953549 | 953550 | 953551 | - | - | ø9 | 102148 (2 pcs.) |
| 511-415/511-418 | |||||||
| 511-416/511-419 | |||||||
| 511-417/511-420 | |||||||
| 511-702/511-732 | 953552 | 953553 | 953554 | 953555 | 953556 | ø12 | 212556 (2 pcs.) |
| 511-703/511-733 | |||||||
| 511-704/511-734 | |||||||
| 511-803/511-833 | |||||||
| 511-804/511-834 | |||||||
| 511-705/511-735 | 953557 | 952361 | 953558 | 953559 | 953560 | ø15 | 212556 (2 pcs.) |
| 511-706/511-736 | |||||||
| 511-805/511-835 | |||||||
| 511-806/511-836 | |||||||
| 511-807/511-837 | |||||||
| 511-808/511-838 | |||||||
Note 1: If an extension rod is attached, the measuring accuracy may degrade due to factors such as rod deflection.
Note 2: Spanner is supplied as standard.
