FCA-50N | Small Type Manual Test Stand | IMADA
ราคาพิเศษ
THB 0.00
THB 0.00
ราคาปรกติ
THB 20,918.50
พร้อมส่ง
SKU
FCA-50N
FCA series is small manual test stand with 50N capacity. It offers high repeatability at budget price by providing a fixed push-in amount.
Features
- Achieves precision measurement with constant testing angle.
- Pushes test sample at a fixed length, which is deal for compression (repulsion) testing of such as spring, cushioning, plastic parts and food.
- Offers high repeatability at budget price by providing a constant push-in amount.
Specifications
| Order No. | FCA-50N |
| Capacity | 50N |
| Stroke | 0～45mm(Adjustable with the limit knob) |
| Maximum Space | 50～80mm (*1) |
| Weight | Approx. 3kg |
| Dimensions | Approx. W175 x H296 x D178mm |
| Compatible force gauge | ZTS, ZTA, DST, DSV (*2) |
| Accessories | Instruction manual, mounting screws, wrench, warranty card |
*1 The distance between the tip of the measuring shaft and the table - differs depending on the force gauge model
and
adjustable with the mounting position of the force gauge.
*2 you cannot combine high capacity model force
gauges with this stand.
*We also offer an food testing unit including this FCA-50N. For further information.
| แบรนด์สินค้า | IMADA |
|---|---|
| Order No. | FCA-50N |
