FEELER GAUGE（ FG SERIES）
Essential for assembly and fitting work.
Can be used by cutting only the necessary size.
USE
●For measurement of gap width
MATERIAL
●Carbon tool steel（ Hardened）（ equivalent to SK7）
FEATURES
●For assemble or adjustment of automotive engine components or other machinery. Can be cut to necessary size.
SPECIFICATIONS
●Leaf width: 12.7mm ●Leaf hardness： HV320 and above
※White powder remains on the surface of the product is antirust agent
| Order No. | Model No. | Size （mm） |
Leaf Width （mm） |
Leaf Length （m） |
Accuracy （mm） |
Case size （mm） |
Weight （Including case） |
| 007253 | FG-03-1 | 0.03x1m | 0.03 | 1 | ±0.005 | Case package 77×77×22 |
36g |
| 007254 | FG-04-1 | 0.04x1m | 0.04 | 37g | |||
| 007255 | FG-05-1 | 0.05x1m | 0.05 | 38g | |||
| 007256 | FG-06-1 | 0.06x1m | 0.06 | 39g | |||
| 007257 | FG-07-1 | 0.07x1m | 0.07 | 40g | |||
| 007258 | FG-08-1 | 0.08x1m | 0.08 | 41g | |||
| 007259 | FG-09-1 | 0.09x1m | 0.09 | 42g | |||
| 007260 | FG-10-1 | 0.10x1m | 0.10 | 43g | |||
| 007261 | FG-11-1 | 0.11x1m | 0.11 | ±0.01 | 44g | ||
| 007262 | FG-12-1 | 0.12x1m | 0.12 | 45g | |||
| 007263 | FG-13-1 | 0.13x1m | 0.13 | 46g | |||
| 007264 | FG-14-1 | 0.14x1m | 0.14 | 47g | |||
| 007265 | FG-15-1 | 0.15x1m | 0.15 | 48g | |||
| 007266 | FG-16-1 | 0.16x1m | 0.16 | 49g | |||
| 007267 | FG-17-1 | 0.17x1m | 0.17 | 50g | |||
| 007268 | FG-18-1 | 0.18x1m | 0.18 | 51g | |||
| 007269 | FG-19-1 | 0.19x1m | 0.19 | 52g | |||
| 007270 | FG-20-1 | 0.20x1m | 0.20 | 53g | |||
| 007275 | FG-25-1 | 0.25x1m | 0.25 | 58g | |||
| 007280 | FG-30-1 | 0.30x1m | 0.30 | 63g | |||
| 007282 | FG-35-1 | 0.35x1m | 0.35 | ±0.012 | Case package 115×115×22 |
121g | |
| 007284 | FG-40-1 | 0.40x1m | 0.40 | 126g | |||
| 007286 | FG-45-1 | 0.45x1m | 0.45 | 133g | |||
| 007287 | FG-50-1 | 0.50x1m | 0.50 | 138g | |||
| 007289 | FG-60-1 | 0.60x1m | 0.60 | ±0.02 | Plastic bag package |
64g | |
| 007291 | FG-70-1 | 0.70x1m | 0.70 | 72g | |||
| 007292 | FG-80-1 | 0.80x1m | 0.80 | 84g | |||
| 007293 | FG-90-1 | 0.90x1m | 0.90 | 92g | |||
| 007294 | FG-00-1 | 1.00x1m | 1.00 | 101g | |||
| 007303 | FG-03-3 | 0.03x3m | 0.03 | 3 | ±0.005 | Case package 77×77×22 |
42g |
| 007304 | FG-04-3 | 0.04x3m | 0.04 | 45g | |||
| 007305 | FG-05-3 | 0.05x3m | 0.05 | 48g | |||
| 007306 | FG-06-3 | 0.06x3m | 0.06 | 51g | |||
| 007307 | FG-07-3 | 0.07x3m | 0.07 | 54g | |||
| 007308 | FG-08-3 | 0.08x3m | 0.08 | 57g | |||
| 007309 | FG-09-3 | 0.09x3m | 0.09 | 60g | |||
| 007310 | FG-10-3 | 0.10x3m | 0.10 | 63g | |||
| 007311 | FG-11-3 | 0.11x3m | 0.11 | ±0.01 | 66g | ||
| 007312 | FG-12-3 | 0.12x3m | 0.12 | 69g | |||
| 007313 | FG-13-3 | 0.13x3m | 0.13 | 72g | |||
| 007314 | FG-14-3 | 0.14x3m | 0.14 | 75g | |||
| 007315 | FG-15-3 | 0.15x3m | 0.15 | Case package 115×115×22 |
130g | ||
| 007317 | FG-20-3 | 0.20x3m | 0.20 | 145g | |||
| 007318 | FG-25-3 | 0.25x3m | 0.25 | 160g | |||
| 007319 | FG-30-3 | 0.30x3m | 0.30 | 176g | |||
| 007321 | FG-35-3 | 0.35x3m | 0.35 | ±0.012 | Plastic bag package |
107g | |
| 007323 | FG-40-3 | 0.40x3m | 0.40 | 140g | |||
| 007325 | FG-45-3 | 0.45x3m | 0.45 | 156g | |||
| 007326 | FG-50-3 | 0.50x3m | 0.50 | 170g | |||
| 007328 | FG-60-3 | 0.60x3m | 0.60 | ±0.02 | 208g | ||
| 007330 | FG-70-3 | 0.70x3m | 0.70 | 234g | |||
| 007331 | FG-80-3 | 0.80x3m | 0.80 | 270g | |||
| 007332 | FG-90-3 | 0.90x3m | 0.90 | 293g | |||
| 007333 | FG-00-3 | 1.00x3m | 1.00 | 320g | |||
| 007343 | FG-03-5 | 0.03x5m | 0.03 | 5 | ±0.005 | Case package 77×77×22 |
48g |
| 007344 | FG-04-5 | 0.04x5m | 0.04 | 53g | |||
| 007345 | FG-05-5 | 0.05x5m | 0.05 | 58g | |||
| 007346 | FG-06-5 | 0.06x5m | 0.06 | 63g | |||
| 007347 | FG-07-5 | 0.07x5m | 0.07 | 68g | |||
| 007348 | FG-08-5 | 0.08x5m | 0.08 | 73g | |||
| 007349 | FG-09-5 | 0.09x5m | 0.09 | 78g | |||
| 007350 | FG-10-5 | 0.10x5m | 0.10 | 83g | |||
| 007351 | FG-11-5 | 0.11x5m | 0.11 | ±0.01 | 88g | ||
| 007352 | FG-12-5 | 0.12x5m | 0.12 | 93g | |||
| 007353 | FG-13-5 | 0.13x5m | 0.13 | 98g | |||
| 007354 | FG-14-5 | 0.14x5m | 0.14 | 103g | |||
| 007355 | FG-15-5 | 0.15x5m | 0.15 | Case package 115×115×22 |
161g | ||
| 007357 | FG-20-5 | 0.20x5m | 0.20 | 185g | |||
| 007358 | FG-25-5 | 0.25x5m | 0.25 | Plastic bag package |
157g | ||
| 007359 | FG-30-5 | 0.30x5m | 0.30 | 184g | |||
| 007361 | FG-35-5 | 0.35x5m | 0.35 | ±0.012 | 211g | ||
| 007363 | FG-40-5 | 0.40x5m | 0.40 | 232g | |||
| 007365 | FG-45-5 | 0.45x5m | 0.45 | 259g | |||
| 007366 | FG-50-5 | 0.50x5m | 0.50 | 282g | |||
| 007368 | FG-60-5 | 0.60x5m | 0.60 | ±0.02 | 345g | ||
| 007370 | FG-70-5 | 0.70x5m | 0.70 | 389g | |||
| 007371 | FG-80-5 | 0.80x5m | 0.80 | 449g | |||
| 007372 | FG-90-5 | 0.90x5m | 0.90 | 487g | |||
| 007373 | FG-00-5 | 1.00x5m | 1.00 | 532g |
| แบรนด์สินค้า | NIIGATA SEIKI (SK) |
|---|
