FEELER GAUGE（ SFG SERIES）
Essential for assembly and fitting work. Made of rust-resistant stainless steel.
Can be used by cutting only the necessary size.
USE
●For measurement of gap width
MATERIAL
●Leaf thickness： 0.01mm Stainless steel SUS301H
0.005・0.02～0.30mm Stainless steel SUS304H
FEATURES
●For assemble or adjustment of automotive engine components or other machinery. Can be cut to necessary size.
SPECIFICATIONS
●Leaf width： 12.7mm
●Leaf hardness： HV300 and above
●Case Size： 77×77×22mm
115×115×22mm（ Order No: 007434〜007439）
| Order No. | Model No. | Size | Leaf Thickness （mm） |
Leaf Length （mm） |
Accuracy （mm） |
Weight （incl. case） |
| 007245 | SFG-005-1 | 0.005x1m | 0.005 | 1 | ±0.004 | 34g |
| 007251 | SFG-01-1 | 0.01x1m | 0.01 | 34g | ||
| 007252 | SFG-02-1 | 0.02x1m | 0.02 | 35g | ||
| 007381 | SFG-03-1 | 0.03x1m | 0.03 | ±0.005 | 36g | |
| 007382 | SFG-04-1 | 0.04x1m | 0.04 | 37g | ||
| 007383 | SFG-05-1 | 0.05x1m | 0.05 | 38g | ||
| 007384 | SFG-06-1 | 0.06x1m | 0.06 | 39g | ||
| 007385 | SFG-07-1 | 0.07x1m | 0.07 | 40g | ||
| 007386 | SFG-08-1 | 0.08x1m | 0.08 | 41g | ||
| 007387 | SFG-09-1 | 0.09x1m | 0.09 | 42g | ||
| 007388 | SFG-10-1 | 0.10x1m | 0.10 | ±0.006 | 43g | |
| 007431 | SFG-15-1 | 0.15x1m | 0.15 | ±0.012 | 50g | |
| 007432 | SFG-20-1 | 0.20x1m | 0.20 | 55g | ||
| 007433 | SFG-30-1 | 0.30x1m | 0.30 | ±0.015 | 65g | |
| 007421 | SFG-01-3 | 0.01x3m | 0.01 | 3 | ±0.004 | 36g |
| 007422 | SFG-02-3 | 0.02x3m | 0.02 | 39g | ||
| 007423 | SFG-03-3 | 0.03x3m | 0.03 | ±0.005 | 42g | |
| 007424 | SFG-04-3 | 0.04x3m | 0.04 | 45g | ||
| 007425 | SFG-05-3 | 0.05x3m | 0.05 | 48g | ||
| 007426 | SFG-06-3 | 0.06x3m | 0.06 | 51g | ||
| 007427 | SFG-07-3 | 0.07x3m | 0.07 | 54g | ||
| 007428 | SFG-08-3 | 0.08x3m | 0.08 | 57g | ||
| 007429 | SFG-09-3 | 0.09x3m | 0.09 | 60g | ||
| 007430 | SFG-10-3 | 0.10x3m | 0.10 | ±0.006 | 63g | |
| 007434 | SFG-15-3 | 0.15x3m | 0.15 | ±0.012 | 130g | |
| 007435 | SFG-20-3 | 0.20x3m | 0.20 | 145g | ||
| 007436 | SFG-30-3 | 0.30x3m | 0.30 | ±0.015 | 175g | |
| 007411 | SFG-01-5 | 0.01x5m | 0.01 | 5 | ±0.004 | 38g |
| 007412 | SFG-02-5 | 0.02x5m | 0.02 | 43g | ||
| 007413 | SFG-03-5 | 0.03x5m | 0.03 | ±0.005 | 48g | |
| 007414 | SFG-04-5 | 0.04x5m | 0.04 | 53g | ||
| 007415 | SFG-05-5 | 0.05x5m | 0.05 | 58g | ||
| 007416 | SFG-06-5 | 0.06x5m | 0.06 | 63g | ||
| 007417 | SFG-07-5 | 0.07x5m | 0.07 | 68g | ||
| 007418 | SFG-08-5 | 0.08x5m | 0.08 | 73g | ||
| 007419 | SFG-09-5 | 0.09x5m | 0.09 | 78g | ||
| 007420 | SFG-10-5 | 0.10x5m | 0.10 | ±0.006 | 83g | |
| 007437 | SFG-15-5 | 0.15x5m | 0.15 | ±0.012 | 160g | |
| 007438 | SFG-20-5 | 0.20x5m | 0.20 | 185g | ||
| 007439 | SFG-30-5 | 0.30x5m | 0.30 | ±0.015 | 235g |
| แบรนด์สินค้า | NIIGATA SEIKI (SK) |
|---|
