GA-FCA | FLAT TYPE COMPRESSION ATTACHMENT | IMADA SEISAKUSHO
ราคาต่ำสุด
THB 0.00
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
GA-FCA
QTY:
0
ATTACHMENTS (JIGS)
Flat type compression attachment
| Type | Max. Load | Diameter | Upper Weight |
|---|---|---|---|
| GA-20 | 500N | φ55mm | 155g |
| GA-20A | 185g | ||
| GA-22 | 10kN | φ100mm | 1.3kg |
| GA-28 | 20kN | 4.1kg | |
| GA-29 | 50kN | 4.2kg | |
| GA-29S | 100kN | 4.3kg |
• GA-20A is a self-centering type.
• Upper flat head of GA-22~29S is a self-centering type, and the extent of alignment can be adjusted.
• Upper flat head of GA-22~29S is a self-centering type, and the extent of alignment can be adjusted.
Dimension
| แบรนด์สินค้า | IMADA SEISAKUSHO |
|---|---|
| Order No. | GA-FCA |
