GAP GAUGES FOR ELECTRIC MOTOR | TSK
สินค้าหมด
SKU
TSK-GAP
Gap gauge for motors is a product with long sequence gauge.
It is mainly used for measuring the clearance between the iron core and the coil of the motor / generator.
| Order No. | Length | No. of leaves |
Leaf combination content (width = 12.7 mm) (unit / mm) | ||||||||
| 300M | 300 | 9 | 0.04 | 0.05 | 0.06 | 0.07 | 0.08 | 0.1 | 0.15 | 0.2 | 0.3 |
| 400M | 400 | 9 | 0.04 | 0.05 | 0.06 | 0.07 | 0.08 | 0.1 | 0.15 | 0.2 | 0.3 |
| 500M | 500 | 9 | 0.04 | 0.05 | 0.06 | 0.07 | 0.08 | 0.1 | 0.15 | 0.2 | 0.3 |
| 600M | 600 | 9 | 0.04 | 0.05 | 0.06 | 0.07 | 0.08 | 0.1 | 0.15 | 0.2 | 0.3 |
| 800M | 800 | 9 | 0.04 | 0.5 | 0.06 | 0.07 | 0.08 | 0.1 | 0.15 | 0.2 | 0.3 |
| 1000M | 1000 | 9 | 0.04 | 0.05 | 0.06 | 0.07 | 0.08 | 0.1 | 0.15 | 0.2 | 0.3 |
※ It is also possible to produce lengths, receiving requests. Please contact us.
