Granite Base Stand and articulated holders with fine adjustment on top | NOGA
สินค้าหมด
SKU
NOGA-GRANITE-ARTICULATED
NOGA Granite Base Stands are made with high quality and hardened granite. NOGA PH holders are the latest improvement of the traditional indicator holder.
• Strong holder lock by using 3 points clamps.
• Fine adjustment on top with universal swivel clamp.
• Holds 6mm, 8mm, 3/8” and dovetail.
• Fast and easy to set up gauges into required position.
• Black finished arms.
| Granite Base Stand & PH Holder Sets | |||
| Set | Granite Base | PH Holder | Total Weight |
| Order no. | Order no. | Order no. | [Kg] |
| MT2010 | MT1000 | PH6410 | 3.050 |
| MT2110 | MT1100 | PH6610 | 5.770 |
| MT2210 | MT1200 | PH6610 | 6.770 |
| MT2310 | MT1300 | PH6810 | 17.050 |
| MT2410 | MT1400 | PH6810 | 31.500 |
| แบรนด์สินค้า | NOGA |
|---|
| Articulated Holder Dimensions | |||
| Articulated Holder | Post | Arm | Bottom Thread |
| Order no. | Dia. (D1) x Length (L1) | Dia. (D2) x Length (L2) | D3 |
| PH6410 | Ø 14 x 203 | Ø 12 x 185 | Ext. M8 |
| PH6610 | Ø 16 x 260 | Ø 16 x 225 | Ext. M8 |
| PH6810 | Ø 18 x 350 | Ø 16 x 225 | Ext. M10 x 1.25 |
| Granite Base Stand Dimensions | |||
| Granite Base Stand | Length | Width | Height |
| Order no. | L | W | H |
| MT1000 | 150 | 100 | 50 |
| MT1100 | 200 | 150 | 50 |
| MT1200 | 260 | 140 | 50 |
| MT1300 | 400 | 250 | 50 |
| MT1400 | 400 | 400 | 60 |
