• These are available in two types: a compact type that can fit in the palm of your hand, and a long type with a slim, easy-to-hold stem. Both are available with an analog or digital indicator.
Order No. | 811-330-10 | 811-332-10 | 811-334-10 | ||
Model | HH-330 | HH-332 | HH-334 | ||
Type | Compact | Long | |||
Display specification | Digital | ||||
Measurement target | Soft rubber, sponge, felt, hard film, fabric |
General rubber, soft plastic |
Hard rubber, hard plastic, ebonite |
||
Category in standards | Type E | Type A | Type D | ||
Needle shape | Shaft diameter | ø5 mm | ø1.25 mm | ||
Tip shape | Semi-sphere | Circular truncated cone | Cone | ||
Tip angle | — | 35° | 30° | ||
Tip diameter | ø0.79 mm | — | |||
Tip curvature | — | 0.1 mm | |||
Power source | SR44 battery (1 pc.), 938882 included as standard (for operational checks) | ||||
External dimensions (W×D×H) | 59×40×147 mm | 59×41×190 mm | |||
Mass | 290 g | 310 g |
Order No. | 811-336-10 | 811-336-11 | 811-338-10 | 811-338-11 | |
Model | HH-336 | HH-336-01 | HH-338 | HH-338-01 | |
Type | Compact | ||||
Display specification | Digital | ||||
Measurement target | General rubber, soft plastic | Hard rubber, hard plastic, ebonite | |||
Category in standards | Type A | Type D | |||
Needle shape | Shaft diameter | ø1.25 mm | |||
Tip shape | Circular truncated cone | Cone | |||
Tip angle | 35° | 30° | |||
Tip diameter | ø0.79 mm | — | |||
Tip curvature | — | 0.1 mm | |||
Power source | SR44 battery (1 pc.), 938882 included as standard (for operational checks) | ||||
External dimensions (W×D×H) | 59×40×147 mm | ||||
Mass | 290 g |
แบรนด์สินค้า | MITUTOYO |
---|
